New products 2014 high resolution full color Led video wall display

Get Latest Price

Payment Type:: T/T

Min. Order:: 8 Piece/Pieces

Min. Order:: 8 Piece/Pieces

Delivery Time:: 15 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)
Supply Ability:	500 Square Meter/Square Meters per Month Led video wall display
Payment Type:	T/T

Product Description

Specifications Led video wall display

Vivid pictures

Superthin; Lightweight

Relative low price

CE,RoHS

New products 2014 high resolution full color Led video wall display Cn10/12 Overview

Cn10/12 is a light, thin and transparent products that very suitable for lighting rental and large square application. Cn10/12 with the performance of light, thin and transparent are very suitable for application on entertainment areas, such as TV stage and clubs. It could be change colors and produce images. The display image are pretty clear, true and magic. Cn10/12 is the best choice for creative designing company to produce large square image. Product Features 1. Light-weight. Saving shipping & labor cost. 2. Nice appearance, good solutions for the overall aesthetic feeling. 3. Jointed correctly, easy to install and dismount. No tool installation. 4. High transparency. Light, air and frost could easily cross through it. 5. Humanized operating interface with breakdown indicator lights. 6. High debugging brightness as 500-1500nit and no damage to gray scale, achieving the debugging technology with wonderful video show. Technological Parameters

Item	Cn10	Cn12
Pixel Pitch	10.4166mm	12.5mm
LED type	RGB 3in1 SMD	RGB 3in1 SMD
Pixel Density	9216dots/m2	6400dots/m2
Resolution	96x48dot	80x40dot
Cabinet size	1000x500x54mm	1000x500x54mm
Weight	7.5kg	7kg
Waterproof rate	IP43	IP43
Brightness	1800CD/m2	1500CD/m2
View Distance	≥10m	≥12m
Viewing Angle (H/V)	120°/120°	120°/120°
Gray Scale	14bit	14bit
Color type	68 Billion	68 Billion
Max.Power Consumption	200W/PCS	200W/PCS
Ave .Power Consumption	70W/PCS	70WPCS
Refresh rate	>960HZ	>1000HZ
Gamma	-5.0~+5.0
Applied environment	INDOOR
Controller	Synchronous display with control PC by DVI
Support Input	Composite ,S-Vide ,Component ,VGA,DVI,HDMI,HD_SDI
Power input	AC90~260 50/60HZ, FSP GROUP
Environment	temperature -10°C~+50°C,humidity 10~90% RH
Operating Life	50,000hours
