0-5v working rohs linear light sensor with best price

Specifications resistor sensor

1.Good test &high sensitivity

2.Fast response

4.14 years experience

5.perfect service

0-5v working rohs linear light sensor with best price    typical applications    1.Replacement of Photoresistor (CdS).
2.Control of backlight brightness for LCD Monitors,TV sets,
3.PDA ,Cameras and Mobile Phones
4.Switch for lighting equipments and Toys     resistor  sensor feature  1.Linear output conforming to illuminance
2.Temperature Stable
3.Low dark current and Low working Lux   resistor sensor Charactieristics

Characteristics	Symbol	Max	Unit
Power Dissipation	PD	10	Mw
Collector-emitter Breakdown Voltage	V(BR)CEO	30	V
Operating temperature range	Topr	-35 to 85	°C
Storage temperature range	Tstg	-35 to 85	°C

      Electrical and Optical Characteristics (Ta= 25°C)

Parameter	Symbol	Test Conditions	Min	Type	Max	Unit
Collector-emitter Breakdown Voltage	BVCEO	IC=100μA ,IB=0	30		100	V
Emitter-collector Breakdown Voltage	BVECO	IE=100μA ,IB=0	5			V
Collector dark current	ICEO	VCE=20V ,H=0mw/cm2			100	nA
Collector-emitter Saturation Voltage	VCE(S)	IC=2mA ,IB=100μA			0.4	V
Rise/fall time	TR/TF	VCE=5V IC=1Ma RL=1000Ω		15/15		μS
Current gain	hFE	VCE=5V ,IC=2Ma	500
Collector-base Capacitance	CCB	F=1MHZ ,VCB=3V	5.4	6.4	7.4	PF
Photo Current	HL	VDD=5V,EV=10LUX	80		130	μA

  More models to Choose:       We are the leading  resistor  sensor manufactuer in China, with 13 years experience in the field of optical electronic parts. Strong back-up of R&D, strict quality control, prompt service, and wide product range----we are waiting to serve you!
