Hook & Eyebolt Clamping Neodymium Magnet

Specifications Hook Neodymium Magnet

1.10 years experience of manufacturer

2.Strong pull force holiding goods

3.Customized Size

4.OEM

Hook Neodymium Magnet:         High Power Neodymium Clamping Magnets with removable hooks are ideal for holding portable lighting to steelwork, holding cables off of the floor on building sites and provide a temporary or permanent hanging point on any steel surface. The smaller sizes are often used in supermarkets to hold promotional signs that are suspended on wires attached to the magnets which are attracted and held to metal ceilings.

      The range consists of 6 magnets from 16mm dia - 60mm dia and with a vertical holding capacity from 5 - 113kgs!The steel hook can be removed and the threaded collar can be used to accept a steel screw or bolt.

      These magnets are only magnetic on their bases and because the ultra strong neodymium magnet is secured inside a strong steel shell, they can be continually clamped onto steel surfaces without cracking or chipping.             For Example:                       D16mm*32mm magnetic hook:

Pack Size:	1
Shape:	Pot/Hook
Magnetic Face:	16mm dia
Thickness:	13mm
Grade:	N35
Plating:	Ni-Cu-Ni ( Nickel )
Material:	NdFeB
Vertical Pull (Kg):	7.5
Slide Resistance (Kg):	1.5
Max Temp (degrees C):	80
Fixing:	Hook Neodymium Magnet

    Hook Neodymium Magnet :We are the leading manufacturers specialized in design and manufacture magnet products with 6 years history in China.We have advanced automatic magnet production equipments and testing instruments. We are gathering a group of experienced professional and technical personnel engaged in manufacturing magnetic materials and magnetic products.Manufacture highly quality neodymium magnets process:   1)high standard raw material;   2)Professional QC team multi-step inspection in finishing maching;   3)Plated by ourself,salt spraying machine test the plating performance;   4)Skillful workers,accurate tolerance,good packing ensure neodymium magnets safety in the transportation;   5)Tolerance: +/-0.05mm for small dimensions, +/-0.1mm for common specifications, +/-0.15mm for big blocks.     Quality Assurance of  Hook Neodymium Magnet: 1). Our quality assurance system in factory meets the requirements of ISO9001:2008 as certified by BM TRADA & UKAS. Our products meet RoHS standard as per test reports issued by an internationally recognized laboratory SGS. Please check the relevant certificate, reports in our website. 2). QC team consists of more than 10 professional people to ensure 100% products high quality.   ISO 9001:2000 Certificate     Neodymium Clamping Magnet: Clamping Magnets with Hooks: thread hole N Hook Neodymium Pot Magnet: Customized Hook Neodymium Magnet: Welcome to inquiry on Hook Neodymium Magnet!
