Four Element Indoor & Outdoor PIR Detector DG-85

Specifications 1.Four Element PIR Detector

2.. Apply 2 Dual PIR Sensor, High Accuracy

3. Pet Immunity (25kg)

4. Both Indoor & Outdoor Usage

Four Element Intelligent Indoor and Outdoor PIR Detector   Features:    •  Adopts 2 dual PIR sensor, provides high accuracy    •  Intelligent ditital chip    •  True motion recognition technology - make accurate judgement of true intruder or other interference    •  Auto memory environmental change - avoid false alarm caused by hot and cold air or opeating machine etc.    •  Pet Immunity - can prevent effectively the interference cause by a 25kg pet or 10 cats, insects, mice, birds etc.    •  Fully sealed design, two-layer waterproof    •  Macromolecule film plating for both  indoor and outdoor installation    •  Super filter (lens) for both indoor & outdoor usage - clear  various interference that common PIR detector can not overcome    •  Two work modes: Relay Mode and Bus Mode --- all kinds of control panels compatible   Technical Specifications:

Input Voltage	9-16V DC
Current Drain	30mA @ 12V DC
Detection Range	11.6m x 11.6m
Alarm Output	N.C., >100mA/28V DC
Tamper Switch	N.C., 100mA/28V DC
Installation Height	2-2.7m
Anti White Light Inteference	> 20000LUX
Anti EMI/RFI	10V/m (10Mhz - 1000Mhz)
Motion Test	0.2m/s - 3.5m/s
Operating Temp	-10°c to 50°c
Storage Temp	-20°c to 60°c
Humidity	5% - 95% (RH)
Dimension	176*85*69mm
