simply Fingerprint and Rfid Card Access Control system

Product Description  1.Introduction: M10 biometric card  & fingerprint access control  is a an newly developed biometric fingerprint Access Control. It is small in size and works standalone. Identification methods are pingerprint, password and card, or their combination. With the capacity to store 500 pingerprint and card enrollment, suitable for factories. 2.Features: It’s simple fingerprint door opener without record Keypad fingerprint door access control device without screen display Industrial-grade design, anti-static circuit to ensure the security, still suitable in strong static environment and thunder or lightning weather. It’s standard version with 3 groups manager’s passwords and 8 groups passwords for user to open the door Completed offline application, no need to connect PC Can set up multi-periods to unlock the door 3. Specifications:

Model	M10
Device Color	Grey
LCD Screen	No
Fingerprint Sensor Resolution	Optical sensor (500DPI)
Authentication Angle	360 0C
Algorithm Version	RSFv5.1
FRR	<0.001%
FAR	<0.0001%
User Capacity	500(Fingerprint/card)
Records Capacity	N/A
Authentication Mode	1:1, 1:N
Identification Time	= 0.5- S
Authentication Method	Fingerprint/ RFID Card (125Khz, EM4100),PIN, Fingerprint + PIN, Card + PIN
Operating Mode	Off-line
Advanced Access Control	Don’t support
Communication	N/A
U Flash Drive	N/A
Lock output	1 group
Exit button	1 group
Wiegand	N/A
Alarm Functions	Tamper proof alarm, door delay alarm, wrong key alarm
Bell	N/A
Voice prompt	buzz
Name prompt	N/A
Language display	N/A
Operating environment	Operating Temp: 0℃-45℃, Humidity: 20%-80%
Power	12V/1A

    Product Overviews     Communication   Packaging & Shipping

Qty/Box	Size/ Box	Weigth/Box
1 PC	15*14*6CM	0.32KG
Qty/Carton	Size/Carton	Weight/Carton
20PCS	31*30*30CM	6.8 KG
