Spanish Finger print Time Attendance/fingerprint reader time attendance A-C091

  Product Description           Brief Introduction  It’s with Western style and big store capacity, metallic coating function keys, and back case is with metal paint process. Its hardware structure adopts structured design of industrial grade. It is with ourselves fingerprint arithmetic which is the most advanced one in the world, automatically analyze the tiny difference of the latest fingerprints vs. the previous fingerprints and update accordingly to ensure the high accuracy and the optimum speed of fingerprint recognition. High recognition ability for injured and peeled fingers, the identification time is less than 0.8 second. With ID card (optional for IC card) function, multi validation methods by card, fingerprint and password combination. It could set up message reminders for meeting, birthday ect, self-define the display & main menu. Standalone to operate the device, U flash drive could realize all kind of setting for the device directly. TCP/IP communication, network connection is simple and convenient. Support Push Technology, operate access control networking and data collection & sharing freely, it’s suitable for high-end office environment. Features: With the most advanced fingerprint arithmetic in the world, automatically analyze the tiny difference of the latest fingerprints vs. the previous fingerprints and update accordingly to ensure the high accuracy and the optimum speed of fingerprint recognition. High recognition ability for injured and peeled fingers, the identification time is less than 0.8 second. Built-in ID card sensor (optional for IC card), validate freely by Card, fingerprint and password combination. 3.2 inch TFT color screen Support U disk to download or upload attendance records and fingerprint data ect. User could enroll the fingerprint in one device, and share the enrollment information with other devices through the USB flash memory. TCP/IP communication, network connection is simple and convenient, support Push Technology, operate access control networking and data collection & sharing freely Supports 11 & 18 digits for user ID registration, user also could enroll mobile number for ID numbers. Authentication modes are 1:1 and 1:N, user can register ten fingers, max fingerprint capacity is 2,000 enrollment and 100,000 records. Warning function for full records and inquiry log functions. Could set up message reminders for meeting, birthday ect and self-define the display & main menu. Support multi development language(VB, C++, C#, Delphi ect) SDK, and ODM/OEM software development   Parameter

Model	K190
LCD Screen	3.2 inch TFT Color Screen
Fingerprint Sensor Resolution	500DPI (Optical sensor)
Hardware Platform	ZDC2911
Algorithm Version	RSFv5.1
CPU	ARM926EJ CPU, Running Frequency: 200MHZ
Communication	TCP/IP, USB Memory Disk, USB cable
User Capacity	3,000
Records Capacity	100,000
Software OS	XP/Win2003/Vista/Win7/Win8 (32bit / 64bit)
Identification Time	< 1 S
Authentication Method	Fingerprint/ RFID Card (125Khz, EM4100) /Password
Language	English
Bell	Built-in timing bell
Operation Mode	Off-line/Online
Power	DC 12V/0.5A
FRR	<1%
FAR	<0.00001%
Operating Mode	Off-line/On-line
Authentication Mode	1:1, 1:N
Operating environment	Operating Temp: 0°C-50°C, Humidity:80%
Certificates	CE, Type Inspection Report of Chinese Police Product
Dimension(L*W*H)mm	Terminal – 190*140*37 Package –325*105*258mmmm
Weight	Terminal – 0.453 Kg, Package- 0.98 Kg

    Product Overviews   Free software       Communication     Packaging & Shipping

Qty/Box	Size/ Box	Weigth/Box
1 PC	28*20*10CM	0.86KG
Qty/Carton	Size/Carton	Weight/Carton
10PCS	55*55*30CM	9KG
