5mm round 660nm deep red Dip Led

Get Latest Price

Delivery Time:: 7 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

5mm round 660nm deep red Dip Led Feature Water clear type 5mm standard directivity superior weather-resistanc Applications Audio equipment Plant grow led Toys Medical led Led light Package size :

Item	Symbol	Value	Unit
DC forward current	I_F	150	mA
Pulse forward current	I_FP	200	mA
Power dissipation	P_D	350	mW
Operating temperature	T_opr	-20~+75	°C
Storage temperature	Y_stg	-30~+80	°C
Reverse voltage	V_R	5	V
Sold soldering temperature	T_sol	260°C/3Sec	---

Item	Symbol	condition	Min	Type	Max	Unit
DC forward Voltage	V_F	I=20mA	2.0	2.2	2.5	V
DC reverse Current	I_R	V=5V	----	----	5	μA
wavelength	Wd	I=20mA	655	660	665	Nm
Spectrum Radiation Bandwidth	Δλ	I=20mA	----	28	----	Nm
Luminous Intensity	I_V	I=20mA	2	----	4	lm
50%Power Angle	2θ1/2	I=20mA	----	30	----	deg
