0.39" red color Single Digit LED Display

0.39" red  color Single Digit  LED  Display    Applications : Audio equipment Instrument panels Digital read out display   Photo:     This  0.39”series is a10*12.9mm high seven segment display designed for viewing distances up to2meters. These displays provide excellent   reliability in bright ambient light. These devices are made with whitesegments and gray surface.     Absolute Maximum Rating                  (Ta=25°C)

Item	Symbol	Value	Unit
Electrostatic Discharge	ESD	3000	V
Forward Current	IFP	25	mA
Power dissipation	PD	120	mW
Operating temperature	Topr	-20~+75	°C
Storage temperature	Ystg	-30~+80	°C
Reverse voltage	VR	5	V
Sold soldering temperature	Tsol	260°C/3Sec(*1)	---

        Initial Electrical/Optical Characteristics                                (Ta=25℃)

Item	Symbol	condition	Min	Type	Max	Unit
forward Voltage Per segment	VF	I=20mA	3.6		4.6	V
forward Voltage Per decimal point			1.8		2.3
reverse Current	IR	V=5V	----	----	100	μA
Chromaticity coordinates*	λ	I=20mA	625	630	635	nm
Spectrum Radiation Bandwidth	Δλ	I=20mA	----	28	----	Nm
Luminous Intensity  Per segment	IV	I=20mA	20	----	50	mcd
Luminous Intensity Per decimal point			10		20
50%Power Angle	2θ1/2	I=20mA	----	120	----	deg

        package size :
