DC12V Infrared 940nm 3528 SMD LED strip light

DC12V Infrared 940nm 3528 SMD LED strip light   discription:   work volt : DC24V   60 pcs 3528 940nm leds per meter   Power :4w   Nonwaterproof   Package:5 meters a reel.   it also can be 30 pcs leds or 120 pcs leds per meter, also can be other infrared led   other colors:   UV(365-400nm),Purple(400-430nm),IR(660-940nm) and so on.   Image:         Absolute Maximum Rating                  (Ta=25℃)

Item		Symbol	Value	Unit
DC forward current  per 3LEDs	3528 LED Item	IF	17-19	mA
	5050 LED Item		51-57
Pulse forward current* per 3LEDs		IFP	100	mA
Operating temperature		Topr	-20~+75	℃
Storage temperature		Ystg	-30~+80	℃
Reverse voltage		VR	5	V

* Plus with Max 10ms,duty ratio max1/10   Initial Electrical/Optical Characteristics                                (Ta=25℃)

Item	Symbol	condition	Min	Type	Max	Unit
DC forward Voltage	VF	DC		12	12.5	V
Viewing  Angle	2θ1/2	DC  12v	----	120	----	deg
