50w 850nm infrared power LED moudle

Specifications 50w 850nm infrared power LED moudle

high power ,

50w  850nm  infrared  power LED moudle       n         Initial Electrical/Optical Characteristics                               (Ta=25°C)

Item	Symbol	condition	Min	Type	Max	Unit
DC forward Voltage	VF	I=1750mA	14	15.5	17	V
DC reverse Current	IR	V=50V	----	----	10	μA
Peak wavelength	λ	I=1750mA	845	850	855	nm
Spectrum Radiation Bandwidth	Δλ	I=1750mA	----	28	----	Nm
Radiant power	IV	I=1750mA	850	----	1350	mw
50%Power Angle	2θ1/2	I=1750mA	----	120	----	deg
Switching time	tr, tf	I=1750mA		20		ns

  NOTES:             Package Dimensions:                       Notes: 1. All dimension units are millimeters. 2. All dimension tolerance is ±0.2mm unless otherwise noted.
