EXFO OTDR FTB-1 with Ethernet Test Module FTB-860

Specifications 1.EXFO OTDR FTB-1 with Ethernet Test Module FTB-860

2.FTB-1/720/730/860

3.Touch screen,can change module

4.IN STOCK!

EXFO OTDR FTB-1 with Ethernet Test Module FTB-860 FTB-1/720/730/860   IN STOCK!!!   please contact Linda Xu:   skype: linda.hsv   Telephone: 0086-755-36934393 website: www.hontek.net   The FTB-1 Platform is a modular platform optimized for fast, powerful, dedicated FTTH and Ethernet test applications    Features: USB, mobile, Wi-Fi and Bluetooth connectivity capabilities Supports third-party applications and all the tools that enable technicians to complete their work right in the field Lets you take advantage of the EXFO Connect environment to manage fi eld testing/reporting operations as well as your platform pool Intel ATOM processor with Windows Embedded Standard operating system, for optimized productivity and versatility Latest battery technology for unmatched operation autonomy One GigE port and two USB 2.0 ports Windows Remote Assistance and Remote Control EXFO fiber inspection probe connector interface Display: TFT outdoor-enhanced LCD, 7-inch touchscreen Telcordia-compliant Specifications:

Display	Touchscreen, color, 800 x 480 TFT, 178 mm (7 in)
Interfaces	Two USB 2.0 ports RJ-45 LAN 10/100/1000 Mbit/s Fiber inspection probe connector port (video) Built-in Bluetooth and Wi-Fi (optional)
Storage	8 GB internal memory (flash) 16 GB internal memory (flash), optional
Batteries	Rechargeable lithium-ion batteries 8 hours of operation as per Telcordia* (Bellcore) TR-NWT-001138
Power supply	AC/DC adapter, input 100-240 VAC, 50-60 Hz, 2 A max, output 24 VDC, 90 W
Computer	Intel ATOM processor Windows Embedded Standard operating system
Size (H x W x D)	190 mm x 252 mm x 66 mm (7 1/2 in x 9 15/16 in x 2 5/8 in)
Weight(with battery)	1.5 kg (3.3 lb)
Temperature	Operating 0°C to 50°C Storage -40°C to 70°C
Relative humidity	0 % to 95 % non-condensing



PM-200 BUILT-IN POWER METER SPECIFICATIONS
Calibrated wavelengths (nm)	850, 1300, 1310, 1490, 1550, 1625, 1650
Optional CWDM calibrated wavelengths (nm)	1270, 1290, 1310, 1330, 1350, 1370, 1390, 1410, 1430, 1450, 1470, 1490, 1510, 1530, 1550,1570, 1590, 1610, 1383, 1625
Power range (dBm)	10 to -86 (InGaAs)
Uncertainty (%)	±5 % ± 3 pW (InGaAs)
Display resolution (dB) InGaAs	0.01 = max to - 76 dBm 0.1 = - 76 dBm to - 86 dBm 1 = - 86 dBm to min
Automatic offset nulling range	Max power to - 63 dBm for InGaAs
Tone detection (Hz)	270/1000/2000
VISUAL FAULT LOCATOR (VFL) (OPTIONAL)
Laser	650 nm ± 10 nm
Typical Pout	in 62.5/125 μm: 3 dBm (2 mW)

    Module:

TK-1-FTB-860

FTB-1 Test Kit, including 10/100/1000 Electrical & 1000 Optical and Fibre Channel 1,2,4XEthernet Test Module Ethernet testing including: - Dual port 10/100/1000 Base-T   Electrical Interface - Dual port 1000 Base-X optical interface - Supports EtherSAM, RFC-2544,Traffic Generation, BERT, Smart Loopback, 3rd party loopback, Ping, Trace Route and Intelligent auto discovery Upgrades note(s): 1- Upgradeable to 100M Optical interface      Order using the following part. no. 100optical 2- Upgradeable to Fibre Channel 1,2 or 4X
