EXFO FIP-400 FIBER INSPECTION PROBE

Specifications EXFO FOT-400 FIBER INSPECTION PROBE

                           EXFO FOT-400 FIBER INSPECTION PROBE     Highly versatile probe to detect dirty/damaged connectors with unparalleled precision
1,Easy back-panel connector inspection
2,Truly rugged and lightweight solution for the fi eld
3,Image-capture capability for report documentation
4,Ideal for all types of connectors: APC, UPC, MTP and more
5,Slim design for easy use in crowded patch panels
6,Compatible with EXFO test instruments
7,FIBER INSPECTION PROBE Next-Generation   SPECIFICATIONS
Video Inspection Probe
Size (H x W x D)
without tip cap 38 mm x 32 mm x 170 mm (1 1/2 in x 1 1/4 in x 6 11/16 in)
with tip cap 38 mm x 32 mm x 200 mm (1 1/2 in x 1 1/4 in x 7 3/4 in)
Weight                                0.2 kg (0.44 lb)
Resolution                            Theoretical < 2 μm, detection capability < 1 μm
Field of view                       625 μm x 464 μm (low magnification) a
                                             412 μm x 306 μm (high magnification)
Light source                        Blue LED
Lighting technique               Coaxial
Capture button b                Present on all models
Connector                          EXFO probe port type (8 pin mini-DIN)
Focus control                     Adjustable on the probe
Optical magnification          Adjustable, low and high (dual model only)     Fiber Probe Viewer
Size                      (H x W x D) 50 mm x 99 mm x 190 mm (1 15/16 in x 3 7/8 in x 7 1/2 in)
Weight c                   0.3 kg (0.66 lb)
LCD screen               3.5 in TFT active matrix (320 x 240 pixels)
Power                        Rechargeable Li-ion battery or AC adapter/charger
Battery life              3 hours (continuous use)
Charging time            4 hours
Connector                  EXFO probe port type (8 pin mini-DIN)
USB Converter           USB 1.1 Model         U SB 2.0 Model

Connectors               EXFO probe port type (8 pin mini-DIN)/USB
Capture button                  No                                            Yes     With EXFO’s FIP-400, you can either use it with a PC, with one of exfo test sets or with exfo lightweight, handheld monitor. Choose the way that works best for you.     Inquire us! we will provide more detail product information,professional suggestion according to your situation!!! Anita Shenzhen Hontek Co., Ltd. Web: www.hontek.net Tel:0086-0755-36934393
