VIVAI OTDR JDSU SMART OTDR/MTS-2000 /MTS-4000/MTS-6000/MTS-8000 OTDR Platform

VIVAI OTDR JDSU SMART OTDR/MTS-2000 /MTS-4000/MTS-6000/MTS-8000 OTDR Platform New JDSU MTS-4000 Test Platform with E4126LM OTDR module and full accessories. All-in-one Access/FTTx/Triple-Play Services Test Set

The MTS-4000 is a small, compact and handheld test platform designed for all phases of the network lifecycle, from the installation to the maintenance of Access/FTTx networks and triple-play services. Modular in design, the MTS-4000 offers field service technicians the highest performance and superior levels of scalability and upgradeability.

Highlights:
Field interchangeable single slot size
In-service testing capability with 1625 or 1650 nm wavelengths
Source and power meter through OTDR port
Simple for the novice, fully featured for the expert
Can be combined with a PON selective power meter module
Compatible with the T-BERD-4000 / MTS-4000 Applications:
Access/FTTx networks construction, turn-up, and maintenance
FTTx feeder fiber characterization
FTTx distribution and drop cable verification and continuity check Key Features:
Optimized for access/FTTx networks
Tests up to three wavelengths in one module
32/30 dB Dynamic Range at 1310/1550 nm
High resolution and short dead zone for distribution fiber qualification
Automatic traffic detection
Source and power meter through OTDR port (optional)
In-service testing dedicated wavelengths (1625 or 1650 nm)
Automatic macro-bend detection
Field-replaceable without tools
Can be combined with PON Power Meter Module in the same T-BERD/MTS-4000 unit
Up to 128,000 acquisition points with sampling resolution down to 4 cm
Comprehensive suite of PC software tools for post-processing of test results, including FiberTrace (OFS-100) and FiberCable (OFS-200)   Ordering information Last Mile 1310/1550 nm OTDR Module E4126LM Last Mile1310/1550/1625 nm OTDR Module E4136LM Last Mile 1310/1550/1650 nm OTDR Module2 E4138LM65 Last Mile 1310/1550 nm and Filtered 1625 nm Module E4136RLM Last Mile 1625 nm OTDR Module E4117LM Last Mile 1650 nm OTDR Module E4118LM65 Last Mile Filtered 1650 nm OTDR Module E4118RLM65 Continuous and modulated source option E41OTDRLS Power meter option E41OTDRPM Universal optical connectors Straight connectors EUNIPCFC, EUNIPCSC, EUNIPCST, EUNIPCDIN, EUNIPCLC 8° angled connectors EUNIAPCFC, EUNIAPCSC, EUNIAPCDIN, EUNIAPCLC
