Sintech Swift F1 Splicing Machine /FTTH optical Fusion splicer

Alignment

Fixed V-Groove(Clad to Clad)

Cladding Diameter

125um

Coating Diameter

250~900um(F1)

Average splice loss

SMF: 0.03dB, MMF: 0.02dB, NZDSF /DSF: 0.06dB

Splice Time (typical)

7 sec

Heating Time

20 sec(0.9mm Fiber)
70sec(Indoor,3.0mm Cable)

Sleeve Length

30mm(0.9mm Fiber)
40mm(2.0,3.0mm,Indoor Cable)

Tension Test

1.96N

Splice Memory

2000

Fiber Holder

For connector only, 900um,250um

Dimension

135(W) × 200(L) × 82(H) mm

Weight

1.5Kg (Body 1.1kg, battery 120g x 2)

Power

DC Li-Polymer Battery, 100 ~ 240VAC Charger

Battery Capacity

1400mAh X 2

No.of Splicing/Heating with battery

typical 120 cycles

Operating Temperature

-10 ~ 50°C

Storage Temperature

-40 ~ 80°c

Description

Model

Working Table

WK

Fiber Holder

HF-250,HF-900,HF-IN

Electrode

EI-19

Blade

BI-05

Cooling Tray

CT

Battery Pack

FI-B

Description

Model

Quantity

Splicer

FI

1

AC Adapter

FI-1

1

Battery Charger

FI-2

1

Battery Pack

FI-B

2

Fiber Holder

HF-205

1set

Spare Electrode

EI-19

1set

Carrying Case

1

Manual

1
