professional TV Signal Level Meters HSV-128

Specifications HSV-128a portable signal level meter is a powerful device designed for the CATV engineers and managers.

                                                         professional TV Signal Level Meters HSV-128 HSV-128  is a portable signal level meter is a powerful device designed for the CATV engineers and managers. This  device can measure data for every technical indicator of the CATV system with high-resolution color display.. This device is special for its function of analyzing all the technical indicators generated by the signal TV.                                                                Technical Data   Frequency/ Channel          Frequency range: 5(47)MHz ~ 870MHz         Channel range:???         Frequency resolution: 10 KHz         Measurement bandwidth: 280KHz   Level Measurement         Range: 25dBuV ~ 120 dBuV         Accuracy: ±2dB         Resolution: 0.1 dB         Scan: peak value demodulation       Input impedance: 75Ω   Carrier-Noise Ratio(C/N)         Input range: 70dBuV—105dBuV         Accuracy: ±2 dBuV   Voltage Measurement          Input range: 10 ~ 80V(AC/DC)         Accuracy: ±2V         Resolution: 0.1V Technical indicators above worked in temperature 25°C   Other Dimensions:215mm×93mm×48mm Net Weight: < 550g Temperature: -10°C ~ 45°C Display:   320 X 240 TFT LCD Audio Output: Build-in speaker   Power   DC supply: 7.2V rechargeable battery   AC Supply:  AC220V/50Hz ±10%   Working time:  >4hrs (full charged battery)
