CE Approved Four Post Hydraulic Burrs Cutting Machine for Metal Products

Specifications Burrs Cutting Machine

1.CE certificated

2.ISO9001 company

3.10 years' manuafacturing and 8 years' exporting experience

 CE Approved Four Post Hydraulic Burrs Cutting Machine for Metal Products   Product Description  Machine Applications This series of hydraulic machines are widely used in: 1. Trimming or cutting and punching aluminum, magnesium alloy etc.metal products; 2. Also applied in whole cut of plastic, re-forming of silicon steel sheet; 3. Blanking, drawing, stamping,of metal, powder products; 4. Most widely used in the die casting industry.       Machine Features and Advantages   The XTM-106K adopts advanced dual oil cylinder,achieves two-stage speed control with sliding block, high speed closing and low speed pressing,high speed back stroke.   1. Frame of 4-column 3-plate design for high grde of parallelism between the active plate and the work platform,and leads to high precision of pressing.   2. Hydraulic pipe system uses integrated circuits manifold block fits inside the press to reduce piping and oil leaks.
  3. Operated by double-button switch.
  4. Selector switch modes of operation: jog (setup) and run (cycle).
  5. Flexibly adjustable pressure and stroke.
6.  Machine dwell time and stroke could be set specially as per processing requirements;
  7. Ideal of double SLC(Security Light Curtain) makes it safe of operation.
  8. Front Side Covers with emergencey switches; Protective fence and the safety interlock can be
added to upgrade the secure.   9. All pipes, flange and joint with vibrations proof and leakage proof design and setting .
  10. Four Goblet shaped Press Feet and idler wheels can be added to make it convenience to locate
and move.
  Technical Parameter(Technical parameter can be customized according to client's need ):

Item	XTM-pro 106 20T	XTM-pro 106 30T	XTM-pro 106 40T	XTM-pro 106 50T
Force	5-20	10-30	10-40	15-50
Work area(mm)	500*400	500*400	600*500	600*500
Max.Operating size(mm)	400	450	500	500
Cylinder stroke(mm)	300	300	300	300
Cylinder descending speed(mm/s)	200	180	150	150
Cylinder compression speed(mm/s)	20	20	15	15
Cylinder hoisting speed(mm/s)	150	130	120	120
Power supply	3ø380VAC,50/60Hz	3ø380VAC,50/60Hz	3ø380VAC,50/60Hz	3ø380VAC,50/60Hz
Motor Power(KW)	2.25	2.25	3.75	3.75

        Machine Details  Overall machine pictures  (The machines below are all according to client's requirement to make)           Machine Accessories       Packaging & Shipping     Company Strength  Shenzhen Xintaiming Machinery Equipment Co., Ltd. is professional researching and developing manufacturer which is specialized in the designing and making    Hydraulic cutting /punching/molding/bending/hot press machine High speed punching machine CNC C-type hydraulic machine              CNC Servo press series IMD/IML hot press molding machine    IMD/IML 3D punching machine  and so on     Our products have been exported to Germany, Hungary, Russia, India, Indonesia, Thailand, Vietnam, the United States, Mexico, Brazil Italy, Saudi Arabia, Bahrain, South Africa, Australia, Iran and so on more than 30 countries and regions    Company Advantages   1. Our own factory manufactures the hydraulic and Pneumatic Presses machine and provides the overall service   2. We master the latest in hydraulic and control technologies and backed by 20 years of worldwide manufacturing expertise.   3.We have a body of engineers who have years of experience   4.Presses can be customized to fit your specific needs and specifications   5. Large-scale  factory.        Workshop& Warehouse     Clients' Visiting and Exhibitions     Certificates:       Business Parnters:
        Why Choose us?   1. We use the world-famous brand accessories like Mitsubishi, Schneider, Siemens, Yuken, Omron etc. Besides. Before packing  machine, we debug machine by letting the machine run for 12 hours.   2. Before packing machine, the machine will run one day for testing oil leakage, repeat error, and electrical  parts performance. Meanwhile, there will be video giving to you(FAT video).   3. Any error(not man-made) happens within the period of guarantee, we offer the according parts for free.    4. we will offer overseas service if we(the Two Parties) can come to an overseas service agreement.
