High Performance 3-8mm Plywood Cutting Machine by CE Certificated

Specifications Plywood Cutting Machine

1.Mature hydraulic technology

2.World-famous brand accessories

3.Strict quality inspection& control

  High Performance 3-8mm Plywood Cutting Machine by CE Certificated   Company Information     Shenzhen Xintaiming Machinery Equipment Co., Ltd. is professional researching and developing manufacturer which is specialized in the designing and making CNC Servo press series, CNC C-type hydraulic machine, IMD/IML 3D punching machine, IMD/IML hot press molding machine, Hydraulic cutting /punching/molding/bending/hot press machine, XTM series four-column single-acting upper displacement oil press and so on.   Our products have been exported to Germany, Hungary, Russia, India, Indonesia, Thailand, Vietnam, the United States, Mexico, Brazil Italy, Saudi Arabia, Bahrain, South Africa, Australia, Iran and so on more than 30 countries  and regions.

Company Advantages: 1. We manufacturesthe hydraulic and Pneumatic Presses machine and provides the overall service.   2. We master the latest hydraulic and control technologies and have 20 years of worldwide manufacturing expertise.   3. We have a body of engineers with years of experience   4. Presses can be customized to meet your specific needs and requirements.   5. A large-scale  factory.   Product Description  Machine Application Scope: 1.Apart from wood cutting, it is also used in burrs cutting and forming die casting products. 2. Cutting, streching and embossing plastic and powder products. It is widely used in auto and motorcycle fitting sectors.    Machine Features: 1.Driven by hydraulic pressure generated by motor, adopts advanced dual oil cylinder and hydraulic circuit, causes low heat while operates at a speed of more than 150mm per second;   2.Hydraulic pressure actuation of 1-14MPA, three-phase alternating current supply, AC380V 50HZ or AC220 60 HZ, total consumptions of electricity of less than 3.7KW(Power supply as per customer request also).   3.The frame adopts integrity welding technology with better regidity and stability of machine while wide convenient operation space;   4.Pressing force, stroke of cutting, dwell time, die height could be adjusted manually comply with practical demand;   5.Intelligent functions: intelligent counter, force measurement monitor, intelligent temperature controller(Customized available).   6.Range of output force: 15ft-100ft.(Optionally).   Technical Parameter: (Technical parameter can be customized according to your special need ):

Model			XTM106K-10	XTM106K-20	XTM106K-30	XTM106K-40	XTM106K-50	XTM106K-60
Nominal Force			10T	20T	30T	40T	50T	60T
Max. Hydraulic Working Pressure			8MPa	16MPa	17Mpa	15.5MPa	15.6MPa	15.5MPa
Knock-out Force			7.6T	3T	3.9T	4.3T	4.8T	5.3T
Worktable Height			780mm	780mm	780mm	780mm	780mm	780mm
Max. Operational Height			400mm	400mm	500mm	500mm	500mm	500mm
Max. Stroke			200mm	300mm	300mm	300mm	300mm	300mm
Dimensions of the Table	L-R		500mm	500mm	500mm	600mm	600mm	600mm
	F-B		400mm	400mm	400mm	500mm	500mm	500mm
Speed of Slide	Descending Speed		≥ 120mm/s	≥142mm/s	≥140mm/s	≥142mm/s	≥142mm/s	≥150mm/s
	Pressing Speed		≥19mm/s	≥16mm/s	≥12mm/s	≥9mm/s	≥7mm/s	≥7mm/s
	Returning Speed		≥100mm/s	≥100mm/s	≥100mm/s	≥82mm/s	≥74mm/s	≥85mm/s
Overall Size of the Machine			700×600×1920(mm)	700×600×2050(mm)	700×600×2250(mm)	700×600×2500(mm)	700×600×2550(mm)	700×600×2600(mm)
Power of Motor			3.75KW	2.2KW	3.7KW	3.7KW	5.5KW	5.5KW

    Operation Steps:              Wood Pices by Machine and Cutting Dies:             Related Product Pictures:                                                                    Packing & Shipping                    Company Strength         Offices                   warehouses                     Exhibitions                 Customers' Visit to XTM     Certification           High Performance 3-8mm Plywood Cutting Machine by CE Certificated
