10.4'' resistive touch lcd digital advertising screen advertising displays

4 Wire Resistive Touch Screen (5.7’’- 22’’) Can be Custom-made   Our direct contact way (Skype): greentouch8   Descriptions of 4 wire resistive touch screen:   4-Wire Resistive touch screen are generally built with two layers of electrically conductive materials (ITO Indium Tin Oxide or ATO Antimony Tin Oxide) separated by insulated dots. When an object touches the device, the two layers come into contact. The contact produces a change in electrical current and is registered as an analog touch event signal. The signal is then sent through the circuit to be converted into a digital signal by the controller for the device to compute the exact location of the touch event.It can be touched by finger, gloved finger, leather or stylus pen.   Advantages of 4 wire resistive touch screen 1. Low cost solution, Low power consumption 2. To be activated with any device
3. Finger, gloved hand and stylus activation
4. High accuracy and sensitivity
5. High durability and reliability
6. Contaminant proof and liquid resistance.   Application of 4 wire resistive touch screen  1. Light industrial
2. Home appliances
3. Portable sport devices
4. Access control terminals
5. Portable medical devices 6. Personal computer and office.     Specification of 4 Wire Resistive Touch Screen

Interface Type:	USB or RS232
Resolution	4096x4096
Screen Ratio	4:3/16:9
Material	ITO Glass + ITO Film/ ITO Film + ITO Film
Certificates	CE, FCC, RoHS
Input method	Finger or touch pen
Position accuracy	1.15~2.5mm
Operating Voltage	DC ≤ 10V
Operating current	5~25mA
Response time	Less than 10ms
Touch action force	20~100g
Operating temperature	-10°C~60°C
Storage temperature	-20°C~70°C
Surface hardness	3H
Working environment	Under sunlight, indoor and outdoor
Transparency	≥80%
Isolation resistance	≥20MΩ DC 25V
X.Y resistance	100Ω~1000Ω according to the size
Linearity	≤1.5%
The number of hits	≥1,000,000/point
Warranty	1 year
Support Systems	Win 2000/Win XP/Win 7/ Win 8/Windows NT/Linux/Android

  Picture Show           Certificates     Payment and Delivery         Factory Show
We are a professional manufacturer of touch products with 8 years’ experience in this field and also a gold supplier on Alibaba. Hope to establish business relationship with you friends from all around the world.
