USB/RS232 Vandal proof SAW touch screen panel

Specifications 1.Sensitive to touch

2.certificate :CE. FCC. RoHS

3.USB connecter or serial port

4.Vandal-proof

5.WIN7/XP/LINUX

  USB/RS232 Vandal/Water proof SAW touch screen panel   SAW Touch screen overview: Standard SAW touch screen, adopts 3mm /4mm or 6mm optical glass with fantastic clarity. Transducers sink into glass beveled edge which can prevent transducers from crush dangerous and facilities assembly. It features unrivaled accuracy, reliability, sensitive and drift free performance, can be touched by fingerer, glove, leather or stylus pen. With controller, it enables you to use both USB and RS232 interface, which enhance convenience and flexibility.   SAW Touch screen Benefits: 1.Superior image clarity with high light transmission 2.Sensitive and fast response 3.Durability, deep scratch resistance and abrasion 4.Highest resolution 5.Activated by finger, gloved hand, leather or soft stylus 6.More than 50 million touches in a single point 7.Dirt and splash sealed capability   SAW touch screen Application: 1.Self service kiosks 2.Vending and ticket sales 3.Electronic catalogs 4.Gaming, lottery, and amusement 5.Public pay phones 6.Multimedia marketing 7.Banking/financial transactions 8.Industrial control rooms 9.Computer-based training   SAW touch screen specification:

No	Item	Specification	No	Item	Specification
1	Item model	GT-SAW-***	15	Response time	≤10ms
2	Detection method	Surface Acoustic Wave	16	Transparency	≥82%
3	Size	10.4” to 19” (extending)	17	Surface hardness	≥5H
4	Aspect ratio	4:3/16:9	18	Material	Pure Glass/Vanda-proof Glass
5	Resolution	4096*4096 ,Z-axis 256, not related with the sizes  of the touch screen panel	19	Thickness	3mm/4MM/6MM
6	Input method	Finger, gloved finger and touch pen	20	Light transmission	≥90%
7	Touch action force	30~60g	21	Durability	Scratch-free; More than 50,000,000 touches  in one location without failure.
8	Position accuracy	2mm	22	Drivers available	Windows 2000/Windows XP/Window 7/ 8Windows NT/Linux/Mac.
9	Operating Voltage	DC ≤10V	23	Certificates	CE, FCC, RoHS
10	Operating current	5~25mA	24	Working environment	Under sunlight, indoor and outdoor
11	Operating temperature	-20°C ~ 60°C	25	Pen hitting life	≥10,000,000/point
12	Storage temperature	-40°C ~ 70°C	26	Pen sliding Durability	≥5,000,000 times
13	Humidity	10%~90% RH at 60°C, non-condensing	27	Finger Touch life	≥35,000,000 times
14	Relative humidity	10%~90% RH at 40°C, non-condensing	28	Warranty	3 year

      Products picture:                        Certifications
