FC single mode optical fiber patch cord

Specifications SC Patch cord

A patch cord can be split into three key components;

the connector

the cable

the manufacturing process

Fiber Optic Patch Cord   LC.SC.FC.ST.MTRJ.MU.SC/APC.FC/APC.MU/APC.E2000...   fiber optic patch cord
fiber optic patch cables
optical fiber patch cord
fiber optic patch cords
lc fiber optic patch cord
mpo-lc fiber optic patch cord
fiber optic patch cord cable
fiber optic patch cord production machine
sc fiber optic patch cord
fc fiber optic patch cord
fiber optic fc fc patch cord...     Patch Cord Connectors   Fiber Optic Connectors are ultra reliable components featuring low insertion loss and return loss. They come with your choice of simplex or duplex cable configuration and are made to conform to IEC, Telcordia GR-326-CORE Standard.   Environmental Reliability Test   The performance of the patchcords has been carefully designed to meet the IEC standards, GR-326-CORE, in the test of optical characteristics, vibration test, thermal cycling, impact resistance, salt spray erosion, thermal aging, humidity resistance and others   Key Features Low insertion loss Low return loss Various connector types available Easy instalation Environmentally stable Applications Fiber Optic Telecommunications LAN (Local Area Network FTTH (Fiber To The Home) CATV&CCTV High speed transmission systems Fiber optic sensing Specifications

Type	Standard, Master
Style	SC/UPC, SC/APC, ST/UPC FC/UPC, FC/APC, LC/UPC LC/APC MU/UPC, SC/UPC Duplex MTRJ/Female, MTRJ/Male
Fiber Type	9/125 SMF-28 or equivalent (Singlemade) 50/125, 62.5/125 (Multimode) 50/125, 10G  (Multimode)
Cable Type	Simplex, Duplex (Zipcord) Φ3.0mm, Φ2.0mm, Φ1.8mm Φ1.6mm PVC or LSZH Φ0.9mm, Φ0.6mm buffered fiber
Insertion Loss	≤ 0.1dB (For Singlemode Master) ≤ 0.25dB (For Singlemode Standard) ≤ 0.25dB (For Multimode) Tested by JDS RM 3750
Return Loss (For Singlemode)	UPC ≥ 50dB SPC ≥ 55dB APC ≥ 60dB (typ.65dB) Tested by JDS RM3750
Repeatability	±0.1dB
Operating temperature	-400C to 800C
Geometry Requirement (For Singlemode)	Ferrule Endface Radius 7mm ≤ R ≤ 12mm (For APC) 10mm ≤ R ≤ 25mm (For Standard) Apex Offset ≤ 30 μm (For Master) Apex Offset ≤ 50 μm (For Standard) Undercut -50nm ≤ U ≤ 50nm Tested by DORC ZX-1

      ------------------------------------------------------------------------------------------------------------------------- ----------------------------------------------------------------------------------------------------------------------------- ======================================================================= ----------------------------------------------------------------------------------------------------------------------------- -------------------------------------------------------------------------------------------------------------------------------------
