SC/PC 12 cores fiber optic pigtail with colorful cable

Specifications SC/PC 12 cores fiber optic pigtail with colorful cable

SpecificationsPrice-Competitive

Low Insertion Loss & PDL

SC/PC 12 cores fiber optic pigtail with colorful cable   Description Single mode pigtails Available in: SPC (Super Physical Contact), UPC (Ultra Physical Contact) or APC (Angled Physical Contact)
Fiber type: G652.D, G655 and G657.A
Construction of secondary protection: tight or loose
Available in 12 colours of primary and secondary protection   SC/PC 12 cores fiber optic pigtail with colorful cable Fiber types: OM1, OM2 and OM3
Construction of secondary protection: tight or loose
Available in 12 colours of primary and secondary protection   Environmental Reliability Test of  SC/PC 12 cores fiber optic pigtail with colorful cable   The performance of the patchcords has been carefully designed to meet the IEC standards, GR-326-CORE, in the test of optical characteristics, vibration test, thermal cycling, impact resistance, salt spray erosion, thermal aging, humidity resistance and others   Key Features of  SC/PC 12 cores fiber optic pigtail with colorful cable Low insertion loss Low return loss Various connector types available Easy instalation Environmentally stable Applications Fiber Optic Telecommunications LAN (Local Area Network FTTH (Fiber To The Home) CATV&CCTV High speed transmission systems Fiber optic sensing Specifications

Type	Standard,Master
Style	LC,SC,ST,FC.MU,DIN,D4,MPO, SC/APC,FC/APC,LC/APC.MU/APC        Duplex MTRJ/Female, MTRJ/Male
Fiber Type	SC/PC 12 cores fiber optic pigtail with colorful cable 9/125 SMF-28 or equivalent (Singlemade) OS1 50/125, 62.5/125 (Multimode) OM2&OM1 50/125, 10G  (Multimode) OM3
Cable Type	SC/PC 12 cores fiber optic pigtail with colorful cable Simplex, Duplex (Zipcord) Φ3.0mm, Φ2.0mm, Φ1.8mm Φ1.6mm PVC or LSZH Φ0.9mm, Φ0.6mm buffered fiber PVC or LSZH
Polishing Manner	UPC,SPC,APC (8°& 6°)
Insertion Loss	≤ 0.1dB (For Singlemode Master) ≤ 0.25dB (For Singlemode Standard) ≤ 0.25dB (For Multimode) Tested by JDS RM 3750
Return Loss (For Singlemode)	UPC ≥ 50dB SPC ≥ 55dB APC ≥ 60dB (typ.65dB) Tested by JDS RM3750
Repeatability	±0.1dB
Operating temperature	-400C to 850C
Geometry Requirement (For Singlemode)	Ferrule Endface Radius 7mm ≤ R ≤ 12mm (For APC) 10mm ≤ R ≤ 25mm (For Standard) Apex Offset ≤ 30 μm (For Master) Apex Offset ≤ 50 μm (For Standard) Undercut -50nm ≤ U ≤ 50nm Tested by DORC ZX-1
