8.4" Industrial Grade Waterproof Touch Monitor

Factory Good Quality 8.4~21.5 Inch Resistive Touch Screen Monitor Industrial Lcd Monitor

The main principle of LCD (Liquid Crystal Display, abbreviated as liquid crystal display in Chinese) is to generate dots, lines, and planes by stimulating liquid crystal molecules with current to form a picture with the back light tube. At present, common liquid crystal display devices are TN, STN, DSTN and TFT. The first three have the same manufacturing principles and become passive matrix liquid crystals, while TFT is more complicated. Because of its memory, it is called active matrix liquid crystal. The display has the advantages of small space, thin panel thickness, light weight, flat right-angle display, low power consumption, no electromagnetic wave radiation, no heat radiation, etc., making it gradually replace the traditional CRT video tube monitor. A liquid crystal display is composed of a liquid crystal panel, a power supply module, a control module and a casing. The liquid crystal panel is as important to the liquid crystal display as the video tube is to the traditional display, and the CPU is to the computer.

Industrial Display Monitors Industrial Touch Screen Displays Industrial Touch Screen Monitors

IP65 PCAP Touch Displays Introduction:

Hengstar design and manufacture a series of Projected Capacitive (PCAP) Touch Displays. These displays adopt aluminum structure, heat can radiate rapidly. Its front bezel and the PCAP touch panel is sealed by one piece silicone rubber, makes it IP65 rating. The displays support VESA mount or panel mount, have been applied to self service kiosks and other industrial control systems.

Main Features:

Industrial grade LCD panel

Vandalism 10 points PCAP touch screen

Touch driver free for Win7/8 OS, USB and RS232 interfaces

Aluminum structure, IP65 rating front screen

VGA+DVI-D signal inputs, auto detect and auto switch

-20~+60C working temperature

Designed for industrial control system, kiosks.

8.4'', 10.4'', 12.1'', 15'', 17'',  19'', 21.5 inch are available

Runs 24 hours a day, 7 days a week, and works normally

IP65 Outdoor Waterproof Grade

Support Touch Screen Optional

Support to be made into an all-in-one pc mode

Standard brightness 250cd/m2 indoor use

Support 1000cd/m2 outdoor use

Resisting extreme enviromenrs

System can be installed, optional: Android/ Windows/ linux multiple choice

8.4 Inch monitor details image

Industrial grade IPS screen + TFT panel

Robust and corrosion resistant
LG, Samsung and other imported screens

3mm emdedded panel
3mm thick front panel
Suitable for all kinds of industrial mall flush mount installation

Standard Interface
Support Extended interface
Support for special interface customization

Touchscreen
5-wire analog resistive touchscreen,Vandal-proof 10 points projected capacitive touchscreen

Mechanical Drawing

Application Scenario

Multiple Installation Method
Embedded, Wall mounted, Panel mounted, and Rack mounted
