Top Selling Conventional Heat Detector with Advanced MCU Expert Algorithm Software

  Top Selling Conventional Heat Detector with Advanced MCU Expert Algorithm Software    Introduction: PY-FT103 is a combined smoke and heat detector with photoelectronic sensor and heat thermistor together.designed to provide open area protection and to be used with most conventional fire alarm control panel. Suitable for home, shop, dance halls, warehouses and other places of the fire alarm system   Features: Compatible with all the conventional fire alarm control panel
Unpolarized wire input
Wide range of operating voltages
High precision electronic thermistor
Built in microprocessor intelligent software
Two LEDs blink standby, provide 360° visibility
Insect-resistant screening
Twist-on mounting base with tamper lock
Remote Indicator LED can be connected    Technical Specifications: Diameter: 103mm
Height (including mounting base): 55 mm
System Voltage (nominal): 24 VDC (9V~ 28VDC)
Standby Current: 40 μA @ 24VDC
Alarm Current: 30 mA @ 24VDC
Fixed Temperature Rating: 57°C (135°F)
Rate of Rise Detection: Responds to greater than 15°F/minOperating Temperature Range: -10°C to 50°C
Operating Humidity Range: 10% to 93% Relative Humidity, Noncondensing
Latching Alarm: Reset by momentary power interruption    If you want to know more about us, welcome to visit our website: www.smart-home-security.cn
