1.25mm right angle fpc connectors pin

Specifications 1.Rich experience in manufacturing

2.ROHS SGS

3.100% tested before delivery

4.Free sample

5.Various types for choice

1.25mm FPC Connector Upper/Entry Contacts, Right Angle       SPECIFICATIONS:

Current Rating	0.75AMP
Operation Temperature	-40°C to +105°C
Contact Resistance	30mΩ Max.
Insulation Resistance	1000MΩ Min.
Withstanding Voltage	AC 500V
Insulator Material	Polyester(UL94V-0) Standard: Nylon-6T
Contact Material	Phosphor bronze
Contact Plating	Au or Sn over 50 u'' Ni

        Engineering drawing:    Ordering Information:

No. of Contacts	Connector Type	Touch Type	Option Type	Color Type
02~36	S=Straight	B=Bottom	W=With Lock	B=Black
	R=Right Angle	U=Upper	N=Without Lock	W=White
		D=Double		E=Beige
				A=Brown

      Our Advantages: 1.All kinds of our products have passed ROHS. 2.Our factory has passed the ISO9001:2000 certification and ISO1400 Certification. 3.We mainly produce the connectors which are used on the Internet,storage,digital computer and other related products. 4.We are glad to make samples according to your drawings and specifications. 5.Available for ODM/OEM order. 6.Please contact us so we can offer you the best quality,competitive price and timely delivery.
