WF5082-TP01 crimp connector housing

Specifications 1.Rich experience in manufacturing

2. Got the certification of ROHS

3.100% tested before delivery

4.Free sample

WF5082-TP01  crimp  connector housing : Specifications:   Current rating:5AMP Operation temperature:-40°C to +105°C Insulation resistance:1000M Ω Min Withstand Volt:1500V AC  Contact resistance:10m Ω max    JL5082series Crimp terminal Part No.:WF5082-TP01 Part Name:WF5082 crimp terminal Contact:Phosphor bronze Plated:tin-plated 50u" min Housing Part No.WF5082-HXXW01 part Name:WF5082Housing Positions:4 Circuits Insulator:Nylon-66 UL94-0 Contact :Phosphor bronze Color:white             Our advantages:
1.All kinds of our products got the certification of ROHS
2.We can take promptly shipment and give you the competitive price with high quality.
3.Rich experience in manufacturing
4.Our products are extensively used in electronic and other industries
5.Well-equipped testing facilities and strong technical force
6.Our factury has passed the the ISO9001:2000 certification and ISO1400 Certificatification
7.We are very glad to make samples according to your graph paper and specification
