Competitive R22 Window Type Air Conditioner

Specifications 1) Intelligent control and display technology

2) Wide voltage design

3) Dual air guide plate technology

Competitive R22 Window Type Air Conditioner     Specifications: 1. Ultra-low noise   2. Self-dignosis   3. Automatic restarst    4. 5 years warranty  5. R22/R410a Gas          Main Features:   1.Intelligent control and display technology 2.Wide voltage design 3.Dual air guide plate technology 4.Memory functions 5.Sleeping mode automatic control 6.Audio prompt diagnosis on failures 7.Timed switch-on and switch-off   Main Specification:

Model No.		KT3C-51GW	KT3CR-51GW	KT3C-70GW	KT3CR-70GW
Control type		Mech/(remote)	Mech/(remote)	Mech/(remote)	Mech/(remote)
Cooling Area-Sq.Ft		323~538	323~538	538~753	538~753
Cooling Capacity-Btu/Hr		18000	18000/18000	24000	24000/24000
E.E.R           BTU/W.H		8.5	8.5	8.5	8.5
COP               W/W		/	2.7	/	2.7
Dehumid. Capacity (Ltrs/Hr)		1.9	1.9	2.2	2.2
Noise Level-dB(A) low/high speed		59/61	59/61	59/61	59/61
Voltage-Volt		220-240	220-240	220-240	220-240
Frequency-Hz		50	50	50	50
Input Current-Amps		9	9.5/8.7	11.8	11.8/11.3
Input Power-W		1950	2100/1900	2800	2800/2700
Refrigerant /Volume		R22/	R22/	R22/	R22/
Chassis Type		fixed	fixed	fixed	fixed
Compressor Type		rotary	rotary	rotary	rotary
Unit Dimension :
Height-Inch		27	27	27	27
Width-Inch		26.4	26.4	26.4	26.4
Depth-Inch		18.1	18.1	18.1	18.1
Packaging Dimension
Height-Inch		31.5	31.5	31.5	31.5
Width-Inch		29.7	29.7	29.7	29.7
Depth-Inch		20.5	20.5	20.5	20.5
Net Weight-lbs.		136.7	136.7	143.3	143.3
Gross Weight-lbs.		143.3	143.3	150	150
Stuffing Quantity (40' HQ)		221	221	221	221
Indoor	Fan type	Centrifugal	Centrifugal	Centrifugal	Centrifugal
	Fan diameter	216	216	216	216
asynchronism motor(iron)	speed H/M/L             (rpm)	1060/950/900	1060/950/900	1060/950/900	1060/950/900
	output-w	160	160	160	160
Outdoor	Fan type	Axial Flow	Axial Flow	Axial Flow	Axial Flow
	Fan diameter	398	398	398	398
evaporator	regular(H/W/D)	373/399/25.4	373/399/25.4	373/399/38.1	373/399/38.1
	coil fin number/Inch	21	21	21	21
condenser	regular(H/W/D)	582/420/25.4	582/420/25.4	582/420/25.4	582/420/25.4
	coil fin number/Inch	21	21	21	21
