96 Wired Zone Burglar Fire Alarm system, IP GPRS Burglar Fire Alarm System

  Product Description

Art. no.:	FC-7688
Dimensions:	(WxHxD) 360x265x80 mm
Housing material:	Metal Box
Installation Location	Indoor use , wall mounted.
LCD Size:	NO
Menu voice guidance:	English
Kit Weight	4.30KG(Without Keypad)
Kit Accessoires Included
	1*FC-7688 LCD
	1*FC-7688
System Network:	TCP/IP GSM PSTN
Number of users:	32
Number of wired zones:	8
Number of bus zones:	88
Number of wireless remote or keypad controls:	8
Number of wired keypad	8
Number of wireless zones:	32
Number of voice phone	4
Number of wireless doorbell	NO
Number of areas	4
Number of wireless switch	NO
Number of wireless siren	1 for dual way siren, multiple for single way siren
Outputs:	NO
GSM Antenna:	External GSM antenna
Event log:	800
Radio frequency:	433MHz/868MHz for options
Integrated siren:	Yes (85dB @ 1m)
Backup battery type	12V DC, 7ah lead acid battery
Max. run time on backup power:	16 h if connect 1 wired keypad
Max. receiving range (outdoors):	150 m
Max. receiving range (building):	100 m
Max. sending range (outdoors):	150 m
Max. sending range (building):	100 m
Power supply unit:	15V/3A
Protocols:	Ademco Contact ID
Tamper monitoring:	Yes
Mobile Client: ST Panel
WEBIE:	192.168.1.200
Meian CMS:	YES
Certifications:	CE,FCC,ROHS

      Our Services      * From sells the date for 12 months, under the normal using of product by the user, if appears in the product quality or functions problems, and belongs to the normal warranty scope of product. We 'll offer 12 month to guarantee the free cost service.   * As for the product exceed to 12 months, in the maintenance, if any small components have problems, such as resistor,  buzzer, capacitor, our company will provide free cost materials. If any main components have problems, such as PC boards, Chips, We 'll quote the basic components price and confirm to you in advance, then for product maintenance. If the product stop the production and have no materals to offer. We 'll return back the origninal product to customers. We 'll suggest every customer to send email for inquiry first then return back your goods.     Company Information      * Our company will return the repair products within 15 days as soon as we receive your goods( exclude the weekend)  Shenzhen Meian Technology Company is a manufacturer specializing in the research, manufacturing, marketing of safety alarm systems, CCTV monitor system, smart home system and automobile articles, with strong design, manufacturing ability, we got ISO9001:2000, CE, CCCs certificate, we have built up a world wide brand Focus in security industry. our product such as beams detectors motion detector, control panel and CCTV cameras are exporting in large quantities to overseas market all over the world, and we build up long time and friendly cooperation with dealers as well as overseas manufacturer for distributor, OEM/ODM service, to be the fixed supplier for army security products or some European countries, as well as American, Middle east, Asia, Australia ect.
