Wireless Transmitter wireless to wired repeater

Specifications Long distance transmit and can amplify the wireless signal to alarm control panel in the environment of strong obstacle.

Wireless Transmitter   PB-205R is wireless transmitter, it adopts MCU for core control, the long distance transmit and in the environment of strong obstacle can amplify the signal to alarm control panel, it can convert up to 60 pcs detectors signal, for avoiding interference, it combined with detectors one by one through learn enrollment mode, and only transmit its attached detectors. It also can convert wireless signal up to 10 kil distance through max wireless 15 transmitters, anti-remove alarm function via built-in buzzer, it has own unique wireless address code (9 digit), when on multi-level transmission, it adopts database exchange mode between the levels transmit the signal including itself address code and detector address code to the next transmitter till the final, the other transmitters are not necessary to learn the detector address code except the first transmitter.   Features: 1. receiving sensibility is -113dB  2. wireless transmit distance ≥1500 meter 3. wireless receiving distance ≥120 meter 4. convert is coding free / up to connect 60pcs wireless detector 5. anti-remove alarm function via built-in Buzzer 6. wireless emitting power is <15mW 7. wireless emitting frequency is 433MHz / 868MHz 8. working / operating voltage is DC 9 ~ 24V / AC 180V ~ 240V 9. working / operating current is 25mA (standby) / 150mA (emitting) 10. built-in rechargeable battery up to 8 hours when power off 11. included 15V/1000mA external power adapter 12. dimension is 167*112*40mm / ivory white color
