High Quality Aluminum Shell 12Vdc 6A IP67 LED Driver 72W Power Supply

Product Description High Quality Aluminum Shell 12Vdc 6A IP67 LED Driver 72W Power Supply
1. AC TO DC Converter
2. Streamline Full Sealed
3. Light Weight & Compact
4. OVP, OCP, SCP
5. Meet RoHS Standard
6. Alaminum Alloy Shell
7. Comply with CE safety standards.
Applied Down Light Driver

Electrical Specifications
Input Voltage	100-330Vac
Voltage Range	97-347Vac
Input Frequency	47-63Hz
Input Current	0.7A max.@100V ac
Power Factor	0.96@220Vac
Hold Time	10ms
Linear Adjustment Rate	±2%
Load Reguation Rate	±5%
Ripple & Noise	<1% Voltage max
Protection Function	OVP, OCP, SCP
Quality Assurance	4 Times 100% Tested - Every pieces of charger would be tested 4 times

Environment Parameters
Operating Temperature	0~+40°c
Storage Temperature	-20~+80°c
Operating Humidity	10%~90% RH: NO Condensation
Storagr Humidity	5%~90% RH
MTBF	5000 Hours Ta=25℃
Cooling Method	Natural Convection
Dimension(L*W*H)(mm)	150*44*33

Model List

Model	Voltage (V)	Current (A)	Efficiency (% min)	Ripple  (P-PmV)	Power (W max)
GS-P240030E618	24	3	82	240	72
GS-P120060E618	12	6	82	120	72

Notes:

This led driver is not suitable for appliances which require an input is more than 6A , Please kindly check the input required for your appliance/device before the purchase.

Using an incorrect led driver may damage your appliance/device and theled driver itself.
Damage to the led driver caused by misuse will not be covered under warranty.
Product Pictures Shipment
Export standard hard cardboard with anti-moisture polybag
The customized packaging is acceptable.
3-5 Working days for sample order, 15-25 days for bulk order
Company Information Company Profile,
Established in 2006, is a professional manufacturer for all kinds of power supplies. our company is located in Shenzhen special economic zone. So far we have over 100 product-line staff and 20 technical staff our products have passed through CE, RoHS, CCC certifications. Our power products have been exported to South Africa, Taiwan, South American countries as well as domestic markets. Grosun makes what customer desires!

Our Service, Do offer you all-demensional "one-station" purchasing service. Esteem and loyalty help us to go further.
Our Main Products, • Wall mounted type adapter
• Desk-top type adapter
• Charger
• Aluminum shell power
• LED driver power
• Inverter

Which are widely used in set-top-boxes, CCTV cameras, LED lights, notebook computers, LED televisions, handheld game devices, etc.
Certifications Our Service 1. For you.
We can help you save cost, beat competitor then earn more profits.

2. Quality assured.
All of our products have passed strict detection, We have many advanced machineries, like Panasonic SMT machines, Panasonic AVK auto component inserters, reflow welding machines, etc. All our products have passed Four Times' Total Testing procedures before shipment.

3. No worries.
We have long-term cooperation with some industry giants like Foxconn, Videocon and UEC. Most of our products have 2 years warranty.

4. OEM is available.
Our professional R&D staff can help you design special model in order to meet your needs. Also we can print your logo on the products if needed.
FAQ 1. Are you a trading company or a factory?
We are a factory. located in Bao’an District, Shenzhen city. which is only about 20 minutes‘ drive from the airport. You are always welcome to visit our factory at any time.
2. Free sample?
Yes, Sampling cost can be returned once bulk order is confirmed.
In some case, we can arrange for free sample if freight is collect.

3. What payment methods do you accept?
We accept TT, L/C at sight, PayPal.

4. What is your defective rate?
Quality is our first goal! Normally our defective rate is below 100ppm.

5. What is your minimum order quantity (MOQ)?
Our MOQ for each model is 1000 PCS.
Samples can be sent for your test before order.
