Spray painting coating robot

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Incoterm:: FOB, CFR, CIF, EXW, FCA

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Transportation:: Ocean, Land

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	500
Supply Ability:	50
Payment Type:	L/C,T/T,Western Union
Incoterm:	FOB,CFR,CIF,EXW,FCA
Certificate:	CE ISO
Transportation:	Ocean,Land

Product Description

spray painting coating robot

The main advantage First, the flexibility is good. (1) The radius of the activity is large and flexible. (2) Spraying of the inner surface and the outer surface can be achieved. (3) It can realize the production of mixed lines of various types of vehicles, such as car, station wagon, pickup truck and other body mixing lines. Second, improve the quality of spraying and material use. (1) The contour of the spray coating is accurate, and the uniformity of the coating film is improved. (2) Reduce the amount of overspray and the amount of cleaning solvent to improve material utilization. Third, easy to operate and maintain. (1) It can be programmed offline, which greatly shortens the on-site debugging time. (2) Plug-in structure and modular design, which can quickly install and replace components, greatly reducing maintenance time. (3) The maintenance of all components is easy to access and easy to maintain. Fourth, the equipment utilization is high.

垂直距离 Vertical Stroke	834.7mm
水平距离 Horizontal Stroke	886.7mm
最大工作半径 Max Working Radius
重复精度 Repeat Positioning Accuracy	±0.5mm
电压 Voltage	220V
功率 Power	360w

Direction for use

1. It adopts robot spraying, uniform paint coating, stable speed, good gloss and high product qualification rate; 2, the spraying robot is environmentally friendly, with high safety performance, easy to operate and easy to learn; 3, the spraying robot has a long service life, no wearing parts, simple maintenance, less wearing parts such as guide rails and belts than the five-axis painting booth; 4, a wide range of applications, suitable for a variety of shaped workpieces, high usage rate, can dynamically track the conveyor belt, with the production line spraying;

Description of application effect

1, built-in fuel-saving procedures, efficient coatings, saving paint 30%; 2, can work 24 hours a day, high reliability, improve production capacity; 3. The height, front, back, front, angle and position of the spray gun can be automatically adjusted according to the change of the sprayed product, and the size of the sprayed oil can be flexibly controlled; 4, the spraying robot has a long service life, no wearing parts, simple maintenance, less wearing parts such as guide rails and belts than the five-axis painting booth; 5, the program can store 3000 groups, U disk copy program can be used, management is convenient and simple;

Detailed Images

The working range is large, the speed is fast, the precision is high, and it is especially suitable for the spraying of complex shaped workpieces, 360 degree no dead angle spraying, 100% uniform. The program can store 3000 groups, and the program can be copied by U disk, which is convenient and simple to manage;

Size Information

Size Chart of This Design

第一轴 Axis 1	±180°	200°/s	第二轴 Axis 2	±115°	200°/s
第三轴 Axis 3	±130°	200°/s	第四轴 Axis 4	±180°	200°/s
第五轴 Axis 5	±165°	200°/s	第六轴 Axis 6	±180°	200°/s

Packing&Shipping

All of our company's wooden boxes are made of exemption materials and can be exported to any country for direct customs clearance. If your product is large in size and needs to be sent from the whole cabinet, our company will fix it with wooden frame, and we will use pe film packaging or packaging according to customer's special requirements.
