Onboard Intel Celeron 1037U processor super thin Industrial

CPU

Intel®1037U Dual core 22nm Processor (1.8GHZ) TDP 17W

Chipset

Intel® HM65 Chipset

Memory

1* SO DDRIII 1333/1066MHz, Max. Up to 8GB

Graphics

Intel® HD Graphics

Offers 1*VGA,2*HDMI,1*LVDS(support Dual 24bit)

support HDMI1/VGA synchronous/asynchronous display

support LVDS/VGA synchronous/asynchronous display

support LVDS/HDMI1 synchronous/asynchronous display

support HDMI1/HDMI2 synchronous/asynchronous display

Expansion Slots

1* Mini-PCIE, support WIFI/3G (Default WIFI)

1* MSATAⅢ, support SSD/USB WIFI(Default USB WIFI)

LAN

2* RTL8111E 10/100/1000Mbps Ethernet,Support Wake-on-LAN and PXE function

(LAN2 is built-in pin header)

Storage

1* SATAⅢ

1* SATAⅢ 2.5-inch laptop hard place

Audio

Integrated Realtek HD ALC662 for 6-Channel output

support MIC/Line-out/Line-in

Rear I/O

4* USB 2.0

1* HDMI

1* VGA

1* RJ-45 LAN

1* Line out(green)

1* Mic (red)

1* 12V DC_JACK input

1* Power or Reset switch(Optional)

Internal I/O

1* LVDS 2*15pin,support dual 24bit LCD

1* JHDMI 2*8Pin

1* JVGA1 2*5pin

2* RS232, the 9th pin supports +5V/+12V charged function

1* LPT

4* USB 2.0(If the Mini-PCIE is a USB signal, supports 2 USB)

1* PS/2 6Pin

1* FP1 (2*5pin Front panel buttons and LED connected)

1* AUDIO pin (Front Audio interface 2*5pin)

1* Amplifier Interface 4pin

1* SIM

1* PWROUT (Hard drive power connector)

1* ATX_12V (Can be used as input and output 12V power connector)

1* LVDS INVERTER

Fun interface

1* CPUFAN 4pin 1* SYSFAN 3pin

GPIO

1* GPIO (Support 4-way GPIO function)

BIOS

AMI 32MB Flash ROM

Watchdog

Support hardware reset function (L256, 0~255 seconds)

Power Input

DC_12VSingle power supply

Operating Temp.

-10°C~60°C

Storage Temp.

-20°C~70°C

Humidity

0%-95%(relative humidity; non-condensing)

Dimension

170mm x 170mm
