Dual LAN NVR ATX NVR Motherboard Support Intel LGA 775 Sock

CPU

Support Intel® LGA 775 Socket Core 2 Duo, Core 2 Quad Processor

Chipset

Intel® G41+82801GR Chipset

Memory

Support 2* DIMM DDR3 1066/800 MHz, Max. up to 4GB

Graphics

Built-in Intel® GMA4500 graphics

support VGA/DVI synchronous/asynchronous display

Expansion Slots

1* PCI-E 16x 1* PCI-E 1x 5* PCI

1* Mini-PCIE(support WIFI)

LAN

2* Intel® 82583V 10/100/1000Mbps Ethernet
Support Wake-on-LAN and PXE

Storage

3* SATAII

1* IDE and CF card

1* Mini SATA(support SSD)

Audio

Integrated Realtek HD ALC662 for 6-Channel output,support MIC / Line-out

Rear I/O

1* PS/2

1* DVI

1* VGA

2* RS232 (COM2 supports RS232/RS422/RS485)

2* RJ-45 LAN

4* USB 2.0

1* AUDIO(MIC / Line out /Line IN)

Internal I/O

8* RS232 (support +5V/+12V charged functions)

1* TX-RXCOM (RS422/485)

1* LPT

4* USB 2.0

1* AUDIO (Front Audio interface 2*5pin)

1* CD_IN Power amplifier interface 4pin

1* FP1 (2*5pin Front panel buttons and LED connector)

1* TPM

Fan interface

1* CPUFAN and SYSFAN 3pin

GPIO

1* GPIO (Support 4-way GPIO function)

BIOS

AMI 16MB Flash ROM

Watchdog

Support hardware reset function (L256, 0~255 seconds)

Power Input

24pinATX Power supply

Operating Temp.

-10°C~60°C

Storage Temp.

-20°C~70°C

Humidity

0%-95%(relative humidity; non-condensing)

Dimension

305mm x 244mm
