240KW300KVA Daewoo Permanent Magnet Generator

Specifications Daewoo Permanent Magnet Generator

-OEM Daewoo

-Increase efficiency 15%

-10 hours operation base tank

-Warranty:1 year

Technical parameters of diesel generator sets:
Technical data
Genset Model	GNR300DS
Prime Power	240KW
Rated Voltage	400/230V
Frequency	50Hz
Power Factor	0.8(lagging)
Dimension (L×W×H) (mm)	2960*1030*1500
Genset weight (kg)	2315
Diesel Engine
Brand	DAEWOO
Model	P126TI-11
Number of Cylinders	6
Total displacement(L)	11.051
Bore (mm)×Stroke(mm)	123*155
Fuel oil consumption rate g/kw.h	63.1
lubricating oil specification and grade	API-CD class above
Fuel oil specification and grade	China 0#(Light diesel oil)
Lubricating system	force and splash lubricating
Speed adjustment mode	Electron
Radiator	Introducing advanced technology for high-low water temperature radiator
Alternator
Brand	Stamford,LeroySomer, Marathon,Engga
Power factor	0.8(Lagging)
Class of insulation	H
Degree of protection	IP23
Voltage regulation	Automatic voltage regulation(AVR)
Sustained Overexcite Time(s)	≥5
Telephone disturbance	THF less than 2%  TIF less than 50
Machine winding	2/3 pitch
Winding temperature rise	H class

     Doosan-Daewoo Heavy Industry Co., Ltd.  in Korea has made recognized achievements in the fields of diesel engines, grabs, vehicles, auto machine tools, robots, etc.With regard to diesel engines, in 1958, it cooperated
with Australia to produce watercraft engines; in 1975, it cooperated with B*W Man in Germany and launched Series D1146-P222LE heavy-duty diesel engines; in 1979, it cooperated with Isuzu in Japan and launched Series DC23-DB58 light-duty diesel engines. In 1990, it founded Daewoo Factory in Europe; in 1994, it founded Daewoo Heavy Industry (Yantai) Co., Ltd.; in 1996, it founded Daewoo Heavy Industry Co., Ltd. in Korea. Daewoo diesel machineries have been widely used in national defense,aviation, vehicles, watercrafts, engineering machineries, generator sets.   Product Specifications /Features
Daewoo series gen-sets have the advantages as small overall dimension, light weight, strong power, energy saving & environment-friend, high reliability and convenient maintenance, which can meet the demands from different customers.   Competitive Advantages
small volume, lightweight, high capability of anti sudden load increase, low noise, economical and reliable,
