50kw Permanent Magnet Generator

Get Latest Price

Payment Type:: L/C, T/T

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Delivery Time:: 25 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)
Supply Ability:	200 Set/Sets per Month
Payment Type:	L/C,T/T

Product Description

Specifications 50kw permanent magnet generator

-OEM Daewoo

-Increase efficiency 15%

-8 hours operation base tank

-Warranty:1 year

50kw Permanent Magnet Generator Our company is an approved Doosan OEM partner. So we can provide Permanent Magnet Generator with very competitive price and comprehensive technical support.

Genset Model	GNR50
Prime Power(kw/kva)	50/63
Standby Power(kw/kva)	55/69
Rated Current(A)	90
Rated Speed(rpm)	1500
Rated Frequency(Hz)	50
Rated Voltage(V)	220V/380V, 230V/400V, 240V/415V
Phase Number	3 phase 4 line
Power Factor	0.8(Laging)
Voltage Regulation	AVR
Genset Structure	Open Type
Noise Decibel(dB(A))	93.7
Engine data
Engine Brand	DOOSAN
Engine Model	DB58
Fuel consumption(L/h)	12.9
Cylinder Number	6L
Bore * Stroke(mm*mm)	102*118
Displacement(L)	5.8
Exhaust Temp(°C)	470
Lub. Capacity(L)	19
Coolant Capacity(L)	36
Starting Voltage(V)	24
Governor	Electronic
Base Fuel Tank	8 hour

Alternator Features: 1. World famous brand AC alternator: Stamford, Leroy Somer, Marathon, Engga 2. Brushless, 4 poles, rotation magnet 3. IP21-23(NEMA1) enclose is standard for all industrial alternators 4. H class insulation system 5. AVR self-regulated, voltage regulation rate: ≤±1% 6. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts 7. Wide range of flange adaptors and single bearing disc coupling 8. Radio interference restraining accords with the stipulation of VDE0875-N and ISO8528 9. Moisture proof, sand-proof, dustproof, salt-proof and vibration-proof Soundproof/Canopy: 1. Excellent ventilation 2. Base Fuel Tank on base frame for 8 Hours working 3. Highly Corrosion Resistant construction 4. New design according to customers' request. 5. Sprayed outdoor powder.
6. 1m<85dBA / 7m<75dBA 7. Super Silent 1m<65dBA Controller: 1. Optional Brand: Smartgen, Deepsea,ComAp , 2. Automatic control panel, LCD display 3. Four protection systems 4. Emergency stop
Optional: 1. Trailer type, Silent Type, Open Type, Container, Automobile 2. ATS (automatic transfer switch) 3. Parallel system 4. Remote system
