Best Quality ! 11KVA Generator Set

Specifications 11KVA Generator Set

1.Famous brand :UK imported engine

2.Stamford alternator

3.Reliable Quality

4.One Years Warranty

          Best Quality !  11KVA Generator Set    UK imported  power generator  have earned a reputation for ease of service along with low costs of maintenance and repair and all Pekins Power part products carry an unequivocal 12-months warranty from date of purchase.

Genset Model	Prime Power		Standby Power		Engine	Fuel Consumption	Cylinder No.	Displacement	Bore X Stroke
	KW	KVA	KW	KVA		(g/kwh)		(L )	(mm)
GNRP10	7	9	8	10	403D-11	≤252	3	1.131	77*81
GNRP15	10	13	12	15	403D-15	≤264	3	1.496	84*94
GNRP23	16	20	18	23	404D-22	≤243	4	2.216	84*100
GNRP33	24	30	26	33	1103A-33G	≤210	3	3.3	105*127
GNRP50	36	45	40	50	1103A-33TG1	≤212	3	3.3	105*127
GNRP65	48	60	52	65	1103A-33TG2	≤211	3	3.3	105*127
GNRP73	52	65	58	73	1104A-44TG1	≤207	4	4.4	105*127
GNRP88	64	80	70	88	1104A-44TG2	≤213	4	4.4	105*127
GNRP103	75	94	82	103	1006TG1A	≤210	6	5.99	100*127
GNRP150	110	138	120	150	1006TAG	≤205	6	5.99	100*127
GNRP165	120	150	132	165	1006TAG2	≤205	6	5.99	100*127

    Features:
1) Engine and alternator shall be mounted on a same frame steel skid
2) Built-in damper for anti-vibration
3) Small size, low weight, easy to operate, installation and maintenance
4) World most famous brand diesel engine: Pekins 1000 series engine-1003G, 1003TG, 1004TG, 1006TG1A, 1006TG2A, 1006TAG
5) World famous brand AC alternator: Stamford
6) Advanced and reliable control module: Key start, auto start 7) Full range protects function and alarm shutdown feature
8) According to professional standards   Soundproof/Silent Box: 1. Excellent ventilation 2. Oil tank mounted on base frame for 12 Hours working 3. Highly Corrosion Resistant construction 4. Excellent Access for Maintenance 5. Security and Safety 6. 1m<80DBA / 7m<70DBA   Control Panel: 1. Automatic control panel (AMF), LCD display 2. Four protection systems 3. Emergency stop   Optional: 1. Trailer type 2. Soundproof / water proof 3. ATS (automatic transfer switch) 4. Parallel system 5. Remote system   Our Advantages: 1. Solve your technical problems in 24 hours and provide international warranty service for engines 2. Design the appearance form according to customers’ request 3. Polyester varnish for appearance protecting for shining and raining 4. Four  hours testing before out factory 5. ISO9001 and CE certification
