100KVA China VOLVO diesel generator with stamford alternator

Specifications 1.Original Volvo engin

2.ABB Circuit Breaker

3.customized samples is acceptable

4.Warranty:12 months & 1000 hours

  85KVA To 625KVA volvo diesel  generator   1,Volvo Series Engine   Volvo, the largest industrial enterprise in Sweden with more than 120 years history, is an engine manufacturer with the longest history in the world. Up to the present, the engine field exceeds 1 million sets, which have been widely used in large and small automobiles, heavy-duty trucks, engineering machineries and ships. Moreover, they are the ideal drive force of power generation sets. Volvo engines have high load capability as well as fast and reliable cold start performance.   2,Alternator   1)Optional Brand: Engga, Stamford, Marathon,leroy somer …   2)The standard generator set matches with Engga brand alternator, and customer also can choose other brands.   3)Standard AVR, AC three phase, 12 reconnect copper leads, single bearing or double bearing, self-exciting system and permanent magnet generator.
4)IP21-23 protection grade, insulation system is H class, and stators are wound to 2/3 pitch.
5)Manufacture standards: GB755, BS5000,VDE0530,NEMAMG1-22,IEC34,and ASB59   3,Digital Control Panel   Controller Brand: Smartgen   Control Panel: English interface,LED screen and touch buttons.   Main Functions:   1- Display loading power, voltage, currenct, frequency, speed, temperature, oil pressure, running time etc.   2- Warning when low or high voltage, low or high frequency, over current, over or low speed, low or over battery voltage etc.   3- Over load protection, over/under frequency protection, over/under/imbalance voltage protection, and low oil shutdown.   4,Optional Diesel Genset Accessories

Engine	Heater	Battery Charger
Fuel System	Daily Fuel Tank	Base Fuel Tank
Control System	Auto Control Panel	Remote Control Panel	Auto Transfer Switch (ATS) Control Panel
Alternator	Single phase, three phase	Brushless, carbon brush
Type	Weatherproof Type	Soundproof Type	Trailer type
Spare Parts	Oil filter, air filter, tank pad, Triangle Belt, tools and Engine Parts Drawing List

  5,Warranty and Maintenance   1) Do the full power load test for five hours before package.   2) One year or 1000 working hours, whichever comes first, global warranty for Cummins.   3) After expiration, we provide spare parts maintenance with low price.     The detail description

Genset Model	Prime Power		Standby Power		Engine	Fuel Consumption	Cylinder No.	Displacement	Bore X Stroke
	KW	KVA	KW	KVA		(g/kwh)		(L )	(mm)
GNRV95	68	85	76	95	TD520GE	≤213	4	4.67	108*130
GNRV110	80	100	88	110	TAD531GE	≤211	4	4.67	108*130
GNRV137	100	125	110	137	TAD532GE	≤204	4	4.67	108*130
GNRV165	120	150	132	165	TAD731GE	≤204	6	6.51	108*130
GNRV200	144	180	160	200	TAD732GE	≤204	6	6.73	108*130
GNRV225	160	200	180	225	TAD733GE	≤204	6	7.28	108*130
GNRV275	200	250	220	275	TAD734GE	≤200	6	7.28	108*135
GNRV350	250	312	280	350	TAD941GE	≤198	6	9.36	131*150
GNRV413	300	375	330	413	TAD1241GE	≤198	6	12.3	131*150
GNRV450	320	400	360	450	TAD1242GE	≤198	6	12.3	131*150
GNRV500	360	450	400	500	TAD1640GE	≤198	6	16.12	144*165
GNRV560	400	500	450	560	TAD1641GE	≤198	6	16.12	144*165
GNRV625	450	563	500	625	TAD1642GE	≤198	6	16.12	144*165
GNRV688	500	625	550	688	TAD1643GE	≤198	6	16.12	144*165
