Welding Dual-use Generator

Specifications Welding Dual-use Generator

1)Yanmar Diesel Generator

2)Soundproof ,Open Type Option

3)Easy Maintenance

4)CE

  Welding Dual-use Generator      Yanmar diesel generator  install original Yanmar diesel engine from Japan, with Stamford or Marathon alternator and Auto-start controller.

Genset Model	Prime Power		Standby Power		Engine Model	NO. of Cylinders	Dimension (mm)	Net Weight
	KW	KVA	KW	KVA			L x W x H	(kg)
GNR7YM	7	8.8	7.7	9.6	3TNV76	3	1580*810*930	300
GNR8.5YM	8.5	11	9.4	12	3TNV82A	3	1580*810*930	320
GNR10YM	10	13	11	14	3TNV88	3	1580*810*930	359
GNR12YM	12	15	13	17	3TNV84T	3	1580*810*930	422
GNR16YM	16	20	18	22	4TNV84T	4	1580*810*990	467
GNR25YM	25	31	28	34	4TNV98	4	1580*810*990	467
GNR32YM	32	40	35	44	4TNV98T	4	1580*810*1165	667
GNR40YM	40	50	44	55	4TNV106	4	1580*810*1165	730
GNR45YM	45	56	50	62	4TNV106T	4	1580*810*1165	730

   Performance of  diesel generator set     Gensets compliance with all main standards, such as :GB/T2820,ISO8528,IEC34,VDE0875-N Prime output power: 7kw to 45kw Rated voltage:400/230v, 440/254v, 220/127v, etc. Phase/connecting method: 3 phase 4wire/Y type connection Rated frequency: 50/60hz Rated speed: 1500/1800rpm Excited type: Brushless, self excited or PMG Insulation: Class H Protection: IP21~IP23 Voltage regulation: AVR automatic control Altitude above sea level: ≤1000 meters Ambient air temperature: ≤40°C Relative air humidity: ≤ 90%    Engine: Yanmar a) 4-stroke
b) Water cooling
c) Direct combustion chamber
d) Supercharging internal cooling
e) Integrated high intensity cylinder    Alternator Engine can be coupled with WT series A.C.synchronous brushless alternator( new-style designed by ourselves,with update international technology). It can also be matched with STAMFORD,LEORY SOMER, MARATHON alternator according to customers’ demand.  Gensets can be open type or soundproof (silent) type.    Controller system 1.Standard control panel, including voltmeter, fequency meter, ampere meter,water temperature gauge, oil temperature gauge, oil pressure gauge, AMF control module,oil level indicator, emergency button,preheating button, battery voltage gauge, hours running counter for protection and tranfering. 2.It can be with ATS electric control cabinet, including circuit breaker,  LCD or LED auto controller, indicating lamp, transfer switch,etc.. Automatic transfer switch (ATS) uses update technology, which can be automatic control for on-off electricity, remote monitoring, automatic parallel operation,etc…   Warranty policy Guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, Genor will provide the free easy-damageable spare parts of diesel engine caused by our quality of production or raw material. After expiration, Genor provides cost spare parts maintenance of diesel engine generator.    Our Advantages: a)Solve your technical problems in 24 hours and provide international warranty service for engines b) Design the appearance form according to customers’ request c) Polyester varnish for appearance protecting for shining and raining d)Two hours testing before out factory e)ISO9001 and CE certification
