8 Sec. Light Weight Splice Fiber Optic Cable / Fibre Optics
  • 8 Sec. Light Weight Splice Fiber Optic Cable / Fibre Optics
8 Sec. Light Weight Splice Fiber Optic Cable / Fibre Optics

8 Sec. Light Weight Splice Fiber Optic Cable / Fibre Optics

Min. Order:
1
Min. Order:
1
Delivery Time:
30 Days
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: Guangdong,China
Product Description
Product Description


8 Sec. Light Weight Splice Fiber Optic Cable / Fibre Optics Splicing FTTH Assembly

Optical fiber fusion splicer design for FTTH. Lightweight and compact makes it is easy to use even

inconfined space. The novel fiber imaging system makes the image clearer. The real time embedded

Operating System provides a friendly man machine interface and abundant functions.The built-in large

capacity Li-Ion battery can support long time field work.

The realtime compensation system for temperature,

humidity and air pressure has greatly enhanced the device against unfavorable environment changes and

thus guarantees its consistency of low loss splicing in various environments.

Features

  • New fully-digital design fusion splicer
  • 5.7 inch digital high definition LCD display
  • PAS technology (Profile Alignment System)
  • Core to core alignment / Cladding alignment / Manual
  • 8 Sec. splice time, 25 Sec. Tube-heat time
  • Close shield splice automatically; Close heater, heat automatically
  • X/Y axes synchronous display, magnification up to 304 time
  • Real time calibrating system for discharging, parameter preseted
  • Long electrode lifetime, up to 4000 times
  • Built-in high capacity battery, up to 220 times splicing or heating
  • Precisely real-time display for battery level.
  • USB and VGA interface
  • Software upgrade via USB interface
  • Small volume, light weight, only 2.8kg including battery

Specification

Item

Specification

Model

AV6471

Applicable fibers

SMF(ITU-T G.652) MMF(ITU-T G.651)

DSF(ITU-T G.653) NZDSF(ITU-T G.655)

Fiber cleaved length

8~16mm (Coating diameter: 250μm)

16mm (Coating diameter: 250~1000μmm)

Fiber diameter

Cladding diameter: 80 ~150μm

Coating diameter: 100~ 1000μm

Fiber count

Single

Align mode

Core to core alignment / Cladding alignment / Manual

Image processing method

Digital

Actual average splicing loss

0.02dB (SM), 0.01dB (MM), 0.04dB (DS), 0.04dB (NZDS)

Return loss

≥60dB

Operation mode

Auto / Half auto / Manual

Splicing time

Typical 8 sec, with standard SM fiber

Magnification

304X(X or Y view),152X(X and Y view)

Image display

5.7' 640×480 LCD.

Tube heating time

Typical 25 sec.

Applicable protection sleeve

40mm, 60mm and a series of micro protection sleeves

Tension test

Standard 2N (optional).

Electrode lifetime

>4000 times, replaceable

Battery capacity

Typically 220 splice times

Charging for 3.5 hours (available when charging).

Battery lifetime

Cycle life up to 300~500 times, replaceable.

Display screen

5.7 inch digital high definition LCD display

Lighting for construction

Built-in super high-brightness LED supply convenience for night work

Termination interface

USB, VGA

Power supply

Built-in 11.1V Li-ion Battery

AC adapter (input AC100~240V, output DC13.5V/4.5A)

Environment adaptation

Temperature range: -10℃~50℃

Humidity: 95%RH (40℃, no condensing)

Altitude:

0~5000m

Dimension

160(L)×Á150(W)×140(H)mm

Weight

2.3kg (no battery ), 2.8kg (including battery)


Packing details

No.

Item

Unit

QTY

Remark

1

AV6471 Fusion Splicer

pcs

1

Main body

2

Inner battery

pcs

1

Accessories

3

AC adapter

pcs

1

Accessories

4

AC power cord

pcs

1

Accessories

5

Spare electrode

set

1

Accessories

6

Blower brush

pcs

1

Accessories

7

Bottle with siphon

pcs

1

Accessories

8

Fiber bracket

pcs

1

Accessories

9

User manual

pcs

1

Accessories

10

Luxury tote kit

pcs

1

Accessories
