Wireless gsm alarm 110 degree long working life 433MHz wireless built-in antenna PIR motion sensor

Wireless gsm alarm 110 degree long working life 433MHz wireless built-in antenna PIR motion sensor

Notice
1. Avoid mounting the detector close to places where heat changes fast or air stream flows frequently
2. Avoid the detector facing to window where can be easily interfered by complicated environment; (eg. sunlight, crowds or moving cars etc)
3. The performance of the detector is optimal when the detection direction is across the walking direction of intruders
Model Number:
KH-PIR
Usage:
motion sensor
Transmitting Frequency:
433MHz
Standby current:
less than 60uA
Operating temp.:
-20 to +55 degrees
Installation mode:
wall mounted
Installation height:
about 2.2m from the ground
Detecting angle:
110 degree
Sending distance:
more than 100m (In the Open Area)
Voltage:
DC 3V
Detection range:
8-15m
Size:
96mm*54mm*38
