LED Strips 100W 12V LED Driver Power Supply Transformer Con
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Guangdong,China |
|---|
Product Description
Product Description
CE RoHS 100W 12V LED Light Power Supply Coffee Colour IP67 Outdoor Waterproof
1. Specification
|
SJ100 - W1V12 | |
| AC input voltage range | 100 - 264VAC 47 - 63HZ | |
| Input Current | 1.5A / 115V ; 0.86A / 230V | |
| AC inrush current | Cold - start current 40A / 230V | |
| Leakage current | < 1 mA / 240VAC | |
| Over load protection | 115 - 135 % hiccupmode,auto-recovery | |
|
115-135% Cut off the output,auto-recovery | |
| Over - temp protection | ≧ 85% ° c Cut off the output, auto-recovery | |
| IP grade | IP67 | |
| Setup rise hold up time | 200ms 100ms 30ms | |
| Withstand voltage | I / P - O / P: 1.5 KvAC 1 minute | |
| I / P - FG:1.5 KvAC 1 minute | ||
| O / P - FG: 0.5 KvAC 1 minute | ||
| Working temperature | ~ 40 ° c ~ + 80 ° c, 20% ~ 90% RH | |
| Weight / packing / Size | 1.06kg, 15pcs / 17.50kg, 255*80*62mm |
2.Warranty treatment:
a> 2 years warranty.
b> 100% burnt-in test, 100% inspection by QC department.
c> We provide the new replacement to customers if it failed in 2 year warranty period.
d> We make sure the defective under 3/1000.
e> It can be used under IP54 level.
3.Incoterms:
a> Delivery term: EX-Work price, it will be the FOB price automatically if the total amount is over 2,5K USD.
b> Payment term: 30% deposit, 70% before shipping the goods.
c> MOQ: 500pcs/each model.
d> Delivery date: 15 wording days after receiving the deposit.
