Custom Jig and Fixture

S45C jig and fixture with induction hardening are most polular workmanship from our clients. Our Jig And Fixture Parts with induction hardening are well received by our clients in the business of automation equipment. 100% inspection is acted in our factory to ensure no Tooling Fixtures in defect will leak out to our clients.

1. Materials that are available for jig and fixture

Fe: Fe360/ 1045/ 1049/ P20/ S136/ M2/ H13/ D2/ 440C/ 4140/ O1
Stainless Steel: 303/ 304/ 316
Al: 2017/ 5052/ 6061/ 7075
Cu: C11000/ C27400 /C34200/ C17200
Resin: Plastic/ Nylon/ POM/ Teflon/ Resin/ POM/ ABS
Else: Bakelite/ Organic glass/ Ti/ Mo / Derlin/ Peek/ Ceramics

2. Metal processing available for jig and fixture

3. Our other parts

4. Tolerance for the jig and fixture
 From simplest to precision of +/- 0.005mm.

5. Files formats accepted when clients send us drawing

 3D: Pro/E . UG . MasterCam
 2D: AutoCad
 Accepted file format: .igs .prt .stp .x_t .dxf .dwg .pdf .jpg .tif .jpg .bmp .doc .xls.

6. SGI service team

7. Delivery for jig and fixture

DHL, FedEx, UPS for small kilos( 2-3 days); By sea for big kilos( 30 days).
