Aluminium double glazed awning window
-
USD150≥100 Square Meter
- Payment Type:
- L/C, T/T, Western Union
- Incoterm:
- FOB, CFR, CIF, EXW
- Min. Order:
- 100 Square Meter
- Min. Order:
- 100 Square Meter
- Delivery Time:
- 20 Days
- Transportation:
- Ocean, Land
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Shenzhen,China |
|---|---|
| Productivity: | 50000 |
| Supply Ability: | 5000 Square.meters/month |
| Payment Type: | L/C,T/T,Western Union |
| Incoterm: | FOB,CFR,CIF,EXW |
| Certificate: | ISO9001:2008 |
| Transportation: | Ocean,Land |
65 series Aluminum awning window,also called Australia Standard Top Hung Window with German Siegenia Hardware or Australian hand opener,optional toughened/Low-E/Laminated/Frost glass,thermal break 6063-T5 aluminum alloy,1.4mm or 2.0mm thickness,powder coated,wood grain or Anodized on aluminum surface is its main specification.Of course,we also get its AS2047,AS2208 certificate from our testing company.
FEATURES
- Available open in or open out.
- Single door or double doors available.
- Full perimeter seal as standard, providing protection from the elements.
- Complete with hinges and multi-point lock hardware.
- Premium satin chrome hardware as standard.
- Radius and elliptical head coupling options.
- Variety of glazing options available, including single glazing, double glazing or low e.
- Unique adjustment system for functional perfection.
- Durable powdercoated finish available in the A&L standard range of colours in your state.
- Backed by our 7 year guarantee.
| Name/Model: | New product inward opening aluminum awning window |
| Standard/Certificate: | comply with AS2047 |
| Glass Standard: | Comply with AS2208 |
| Structural glazing: | Comply with ISO9001:2008 |
| Profiles: | High quality thermal/non-thermal break |
|
6063-T5 Xingfa Aluminum Alloy Profile |
|
| Glass choice: | Low-e; relective;Frosted; tinted; clear tempered glazing |
| 5mm; 12mm single tempered glazing | |
| 5+12A+5mm; 5+27A+5mm; 6+12A+6mm double glass | |
| 5+6A+5+6A+5mm triple glass | |
| 5+0.76+5mm;6+2.28+6mm Laminated | |
| Hardware: | Australia doric;German Siegenia/Roto;China Top brand |
| Surface finish: | Powder coated meet AS 3715; Electrophoresis; flucarbon; Anodizing; wood grain |
| Color: | Customized (matt black;white;ultra silver;clear anodized;nature clean aluminium) |
| Flyscreen: | Stainless steel security mesh; Aluminium security mesh; Fiberglass flyscreen |
| Retractable Screen, Fixed Screen, Sliding Screen, etc. | |
| Security: | crimsafe mesh ; grille available |
| Main market: | Australia,Canada,New Zealand,America |
| Guarantee Period: | 10 Years |
| Production Experience: | 10 Years |
| Application: | residentials series; commerical series; modular house,steel structure house, etc |
| Wall Type: | meet double brick; brick vaneer; concrete; wooden frame; steel structure |
| subframes: | angels; timber reveals; sub-head; sub sills available |
Packaging Details:
1.Protective tape protects frames from scratches;
2.Keep windows or doors fixed on iron pallets;
3.Tie up windows or doors on the iron pallets with plastic belts;
4.PE films to keep away from sea water;
5.Fill in the space between each two iron pallets by air bags;
6.Tie up iron pallets in container with plastic belts.
Our packages will ensure the windows and doors arrive at project jobsite in good conditions. Pictures are available if details of packages needed.
