2 core SM G657A butterfly indoor FTTH drop cable
Description
The typical GJXFH bow-type drop optical cable includes central optical fibre(s) with 2 parallel KFRPs as the strength members placed on both sides, a LSZH sheath is extruded outside.
Characters:
1. Simple structure, light weight, high tensile strength and metalfree;
2. Novel groove design, easily strip and splice, simplified installation and maintenance;
3. Low smoke, zero halogen and flame retardant sheath, environment-friendly, good safety
Technical Parameters
Description
The typical GJXFH bow-type drop optical cable includes central optical fibre(s) with 2 parallel KFRPs as the strength members placed on both sides, a LSZH sheath is extruded outside.
Characters:
1. Simple structure, light weight, high tensile strength and metalfree;
2. Novel groove design, easily strip and splice, simplified installation and maintenance;
3. Low smoke, zero halogen and flame retardant sheath, environment-friendly, good safety
| G.652 | G.655 | 50/125μm | 62.5/125μm | ||
|
Attenuation (+20°C) |
@850nm |
|
|
≤3.5 dB/km | ≤3.5 dB/km |
| @1300nm |
|
|
≤1.5 dB/km | ≤1.5 dB/km | |
| @1310nm | ≤0.45 dB/km | ≤0.50 dB/km |
|
|
|
| @1550nm | ≤0.30 dB/km | ≤0.50dB/km |
|
|
|
|
Bandwidth (Class A) |
@850nm |
|
|
≥500 MHz·km | ≥200 MHz·km |
| @1300nm |
|
|
≥1000 MHz·km | ≥600 MHz·km | |
| Numerical Aperture |
|
|
0.200±0.015NA | 0.275±0.015NA | |
| Cable Cut-off Wavelength λcc | ≤1260nm | ≤1480nm |
|
|
|
Technical Parameters
| Fiber Count |
Cable Diameter mm |
Cable Weight kg/km |
Tensile Strength Long/Short Term N |
Crush Resistance Long/Short Term N/100mm |
Bending Radius Static /Dynamic mm |
| 1 | (2.0±0.2)×(3.0±0.2) | 8 | 30/60 | 300/1000 | 15/30 |
| 2 | (2.0±0.2)×(3.4±0.2) | 8.5 | 30/60 | 300/1000 | 15/30 |
| 1 | (2.0±0.2)×(3.8±0.2) | 9 | 30/60 | 300/1000 | 15/30 |
| 4 | (2.0±0.2)×(4.0±0.2) | 10 | 30/60 | 300/1000 | 15/30 |
