GPS Tracking external antenna with MCX

GPS external receiving antenna, is the satellite wireless electromagnetic energy is transformed into the receiver electronics can supply intake applications. Our GPS external antenna is composed of a ceramic body. The plastic shell antenna signal package, has the characteristics of waterproof products, the volume is small, the antenna is arranged at the bottom of 3M glue, convenient installation and use.

Operating conditions

Temperature: -40°C~+80°C

Humidity:95%~100%

Storage conditions

Temperature:-45°C~+85°C

Humidity: 95%~100%

Antenna specifications

Range of receiving frequency: 1575.42±1.1 MHz

Center frequency: 1575.42

Band width: ≥10

V.S.W.R.: ≤2.0

Gain: 3dB

Axial ratio: 3.0dB

Polarization: Right-handed circular

Impedance: 50Ω

Frequency temperature coefficient: 0±10

Amplifier specifications

Range of frequency: 1575.42±3MHz

Amplifier gain: 26±3dB

V.S.W.R.: ≤2.0

Noise factor: ﹤2.0

Volts D.C.: 3~5V

Direct current: ≤20mA
