16 AWG Silicone Wire tinned ends ,welding cable Soft and flexible
High Temperature Resistant Silicone Wire.Temp:-60 degree~+200 degree; Rated Voltage:600V
Highly efficient - Super low impedance , 252 strands of 0.08 mm copper wire
Main Industry Application Products
- Bone Conduction Transduer
- Speed Sensor ; Angle Snesor ; Temperture Sensor ; Urea Sensor
- CNC Equipment Robot Arm
- AED ; Electrocardiograph
Description of Ultra Soft Silicon Cable High Temperature
- Conductor structure: see common conductor structure table or customization
- Insulation : FEP/SILICONE/PFA/ETFE
- Sheath material : silicone rubber
- Working temperature : -60 ℃--200 ℃
- Retardant grade: 94V-0
- Production range: standard section 0.03-5 square meter or customization
- Multiple conductors: 1-37 conductors or customization
Feature Of Ultra Soft Silicon Cable High Temperature
- Excellent Performance Of High / Low Temperature Resistance
- Electrical Insulated;Chemical Stability
- High Voltage Resistance
- Aging Resistance;Water Resistance
- Weather Resistance Long ServiceLife
- Flexible And Easy To Install And Process
-
Platinum Sulfide Technology;Lame Retardant, Environmental Halogen Free
Details HD Photo Of Ultra Soft Silicon Cable High Temperature
The Application Of Our Ultra Soft Silicon Cable High Temperature
Silicone Cable's Application On CNC Equipment,Sencor And Connector Such Like Those Connector Production By Lemo,ODU:
Base On The Features Of Ultra Soft Silicon Cable High Temperature
Silicone Cable's Application On Medical Equipmet:
Base On The Features Of Ultra Soft Silicon Cable High Temperature
Specification Data Sheet Of Our Nomal Ultra Soft Silicon Cable High Temperature
| P/N | Normal Spec. | Twisting OD | Resosyamce/KM | Standard OD | Conductor(Option) | Filling(Option) |
| 10 | 105/0.2541/2.588 | 2.588 | <5 | 3.2 |
99.99% Copper Tinned Copper Varnished Wire Sliver-Plated Copper Nickel Copper |
Kevlar/Nylon |
| 12 | 65/0.254 1/2.05 | 2.05 | <7 | 2.65 | Kevlar/Nylon | |
| 14 | 41/0.254 1/1.63 | 1.63 | <10 | 2.2 | Kevlar/Nylon | |
| 16 | 26/0.254 1/1.29 | 1.29 | <15 | 1.9 | Kevlar/Nylon | |
| 18 | 41/0.16 165/0.08 105/0.11 | 1.02 | <25 | 1.6 | Kevlar/Nylon | |
| 20 | 20/0.16 110/0.08 70/0.1 | 0.81 | <35 | 1.4 | Kevlar/Nylon | |
| 22 | 17/0.16 65/0.08 41/0.1 | 0.64 | <55 | 1.2 | Kevlar/Nylon | |
| 24 | 26/0.1 41/0.08 120/0.05 | 0.58 | <90 | 1 | Kevlar/Nylon | |
| 26 | 7/0.16 24/0.08 65/0.05 | 0.48 | <125 | 0.9 | Kevlar/Nylon | |
| 28 | 11/0.1 19/0.08 45/0.05 | 0.38 | <210 | 0.85 | Kevlar/Nylon | |
| 30 | 7/0.1 19/0.06 28/0.05 1/0.3 | 0.3 | <320 | 0.7 | Kevlar/Nylon | |
| 32 | 1/0.254 7/0.08 18/0.05 | 0.2 | <500 | 0.55 | Kevlar/Nylon | |
| 34 | 1/0.2 7/0.06 | 0.2 | <560 | 0.45 | Kevlar/Nylon | |
| 36 | 1/0.16 7/0.05 | 0.16 | <870 | Kevlar/Nylon | ||
| 38 | 1/0.127 7/0.04 | 0.12 | <1400 | Kevlar/Nylon | ||
| 40 | 1/0.08 | 0.08 | <3500 |
Kevlar/Nylon |
Specification Data Sheet Of Our Ultra Soft Silicon Cable High Temperature
| P/N | Normal Spec. | Twisting OD | Resosyamce/KM | Standard OD | Conductor(Option) | Filling(Option) |
| 10 | 105/0.2541/2.588 | 2.588 | <5 | 3.2 |
99.99% Copper Tinned Copper Sliver-Plated Copper Nickel Copper |
NO |
| 12 | 65/0.254 1/2.05 | 2.05 | <7 | 2.65 | NO | |
| 14 | 41/0.254 1/1.63 | 1.63 | <10 | 2.2 | NO | |
| 16 | 26/0.254 1/1.29 | 1.29 | <15 | 1.9 | NO | |
| 18 | 41/0.16 165/0.08 105/0.11 | 1.02 | <25 | 1.6 | NO | |
| 20 | 20/0.16 110/0.08 70/0.1 | 0.81 | <35 | 1.4 | NO | |
| 22 | 17/0.16 65/0.08 41/0.1 | 0.64 | <55 | 1.2 | NO | |
| 24 | 26/0.1 41/0.08 120/0.05 | 0.58 | <90 | 1 | NO | |
| 26 | 7/0.16 24/0.08 65/0.05 | 0.48 | <125 | 0.9 | NO | |
| 28 | 11/0.1 19/0.08 45/0.05 | 0.38 | <210 | 0.85 | NO | |
| 30 | 7/0.1 19/0.06 28/0.05 1/0.3 | 0.3 | <320 | 0.7 | NO | |
| 32 | 1/0.254 7/0.08 18/0.05 | 0.2 | <500 | 0.55 | NO | |
| 34 | 1/0.2 7/0.06 | 0.2 | <560 | 0.45 | NO | |
| 36 | 1/0.16 7/0.05 | 0.16 | <870 | NO | ||
| 38 | 1/0.127 7/0.04 | 0.12 | <1400 | NO | ||
| 40 | 1/0.08 | 0.08 | <3500 |
NO |
