1. Power Supply: AC220V±10V ,50Hz / AC110V±10V ,60Hz

2. Power Consumption: 100W

3. Temperature: -15 to 60 degrees

4. Humidity: <95%, without concretion

5. Passage Width: 600mm

6. Passing Speed: 30 persons/min (normal open), 20 persons/min (normal close)

7. Arm Open/Close Time: 2s

8. Input Interface: +12V electrical signal or impulse signal with width more than 100ms, drive current >10mA

9. Communication Interface: RS485 (Distance: <=1200m)

10. Working Environment: Indoors or outdoors with shed

11. Arm Turning: Uni-direction or Bi-direction

Main Functions:

1. Auto-reposition function: After card read, passengers don`t pass within regulated time period, turnstile will be locked automatically

2. Bi-direction passing or uni-direction

3. When power off, arm will be dropped automatically

4. Self-lock function: arm will be locked automatically after passenger passing

5. LED passing arrow can show direction to indicate passenger to pass

6. Standard interfaces are convenient for connection with different readers which can send relay signal

7. RS485 interfaces can connect turnstile with computer directly

8. Stable running with little noise

Material:

○ 202 stainless steel

● 304 stainless steel

○ 316 stainless steel

Structure:

1. Dimension

1200x280x990mm

2. Arm diameter

○ Φ 32(diameter)

● Φ 38(diameter)

○ Φ 42(diameter)
