Yaskawa AC Drive A1000 Performance Vector Control Drive
3/4 – 1000 HP
The A1000 is a full featured drive, providing outstanding quality, performance, flexibility, and environmental friendliness through 1000HP. Enjoy network communications, feedback, and expandable I/O to control anything from simple fans and pumps to complex machines. For new installations or retrofits, the A1000 provides a single robust solution, regardless of your application.
Feature Highlights
Closed or open loop vector control for outstanding regulation, torque production, and position control capability.
Continuous Auto-tuning optimizes performance by compensating for changes in motor temperature.
High Frequency Injection enables high precision open loop control of Interior Permanent Magnet Motors.
Fast acting current and voltage limiters help achieve continuous drive operation during periods of excessive demand.
High Slip Braking reduces installation cost and the need for dynamic braking resistors
Communication options for all major industrial networks provides high speed control and monitoring, reducing installation cost.
DriveWizard computer software and Application Sets for easy configuration.
Auxiliary Control Power Unit maximizes production time and efficiency by maintaining network communication while main power is removed.
Embedded Safe Torque Off minimizes downtime for applications requiring occasional intervention (SIL CL2, PLd, Category 3).
Embedded function blocks, programmable with DriveWorks EZ, provide additional application flexibility and the opportunity to eliminate separate controllers.
USB Copy Unit and Keypad configuration storage provide speed and convenience for duplicate configuration of multiple drives.
Removable terminal board with configuration storage provides convenience of configuration backup.
Made with RoHS compliant materials.
Integrated DC Reactor (standard on 30HP and larger) for input harmonic reduction.
Kinetic Energy Braking allows drive to remain in control during momentary power losses.
Integrated 12 Pulse version provides a cost effective solution for low harmonics.
Flange version provides NEMA 12 backside integrity when mounting with heatsink external.
200-240V, 3-Phase, Protected Chassis/NEMA 1
|
DRIVE MODEL NUMBER STANDARD |
NORMAL DUTY (ND)1 |
HEAVY DUTY (HD)1 |
STANDARD ENCLOSURE |
||
|
RATED OUTPUT CURRENT (AMPS) |
NOMINAL HP2 |
RATED OUTPUT CURRENT (AMPS) |
NOMINAL HP2 |
||
|
CIMR-AU2A0004FAA |
3.5 |
3/4 |
3.2 |
3/4 |
NEMA 1 |
|
CIMR-AU2A0006FAA |
6 |
1 |
5 |
1 |
|
|
CIMR-AU2A0008FAA |
8 |
2 |
6.9 |
2 |
|
|
CIMR-AU2A0010FAA |
9.6 |
2 |
8 |
2 |
NEMA 1 |
|
CIMR-AU2A0012FAA |
12 |
3 |
11 |
3 |
|
|
CIMR-AU2A0018FAA |
17.5 |
5 |
14 |
3 |
|
|
CIMR-AU2A0021FAA |
21 |
7.5 |
17.5 |
5 |
NEMA 1 |
|
CIMR-AU2A0030FAA |
30 |
10 |
25 |
7.5 |
|
|
CIMR-AU2A0040FAA |
40 |
15 |
33 |
10 |
|
|
CIMR-AU2A0056FAA |
56 |
20 |
47 |
15 |
NEMA 1 |
|
CIMR-AU2A0069FAA |
69 |
25 |
60 |
20 |
|
|
CIMR-AU2A0081FAA |
81 |
30 |
75 |
25 |
|
|
CIMR-AU2A0110FAA |
110 |
40 |
85 |
30 |
NEMA 1 |
|
CIMR-AU2A0138FAA |
138 |
50 |
115 |
40 |
|
|
CIMR-AU2A0169FAA |
169 |
60 |
145 |
50 |
NEMA 1 |
|
CIMR-AU2A0211FAA |
211 |
75 |
180 |
60 |
|
|
CIMR-AU2A0250AAA |
250 |
100 |
215 |
75 |
Protected Chassis |
|
CIMR-AU2A0312AAA |
312 |
125 |
283 |
100 |
|
|
CIMR-AU2A0360AAA |
360 |
150 |
346 |
125 |
Protected Chassis |
|
CIMR-AU2A0415AAA |
415 |
175 |
415 |
150 |
|
Specifications
|
ITEM |
SPECIFICATION |
|
Overload Capacity |
150% for 60 sec. (HD), 120% for 60 sec. (ND) |
|
Output Frequency |
0~400 Hz (higher frequencies available with custom software) |
|
Control Methods |
Open and Closed Loop Current Vector; |
|
Motor Types |
Induction |
|
Protective Design |
IP20/NEMA1/FLANGE (NEMA 12 backside) |
|
Ambient Operating Temperature |
-10 to +50°C (Chassis Installation) |
|
Braking Transistor |
Standard through 50HP (ND), 40HP (HD) |
|
Global Certification |
UL, CSA, CE, C-Tick, RoHS |
|
Standard I/O |
(8) multi-function digital inputs (24Vdc) |
|
(3) multi-function analog inputs (0 +/- 10 VDC, 4-20 mA) |
|
|
(1) multi-function pulse inputs |
|
|
(1) fault relay output (form C) |
|
|
(3) multi-function relay outputs (form A) |
|
|
(2) multi-function analog output (0 +/- 10 VDC, 4-20mA) |
|
|
(1) multi-function pulse output |
|
|
I/O Expansion |
3 Analog Inputs -10 to +10V, 13 bit plus sign, 4 to
20mA |
|
Feedback |
Incremental |
|
Network Communication |
Built-in: Modbus RTU, RS-422/485, 115 kbps |
|
Optional: EtherNet IP, DeviceNet, Modbus TCP/IP, PROFINET, PROFIBUS-DP, MECHATROLINK-II |
|
|
Speed Control Range |
1500:1 Closed Loop Vector (IM and PM Motors) |
|
Speed Control Accuracy |
£ 0.02%: Closed Loop Vector; ≤ 0.2%; Open Loop Vector |
|
Speed Response |
≥ 60 Hz: Closed Loop Vector; ≥ 10 Hz: Open Loop Vector |
|
Torque Response |
≥ 300 Hz: Closed Loop Vector |
|
Function Block Diagrams |
Up to 100 connections, 1ms program scan time |
