22Antennas Wireless Signal Jammer Full Bands 42Watt Infrared
- Min. Order:
- 1 Others
- Min. Order:
- 1 Others
- Transportation:
- Ocean, Land, Express, Air
- Port:
- SHENZHEN, GUANGZHOU, HONGKONG
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | CHINA |
|---|---|
| Supply Ability: | 2000 |
| Certificate: | ISO |
| Transportation: | Ocean,Land,Express,Air |
| Port: | SHENZHEN,GUANGZHOU,HONGKONG |
This is the latest designed with 22 Antennas all-in-one for mobile phone 5GLTE GSM 3G 4GLTE signals which bring us a strong UAV Drone Jamming Module ability. And it can not only cut off all 5G 3G 4G mobile phone signals, but also jam Wi-Fi2.4G/5GHz GPS LOJACK, RF 315 MHz 433MHz , VHF UHF Walkie-Talkie & Wireless Headset/Microphone signals. Full bands jammer is power full to blocks all the signals, UAV Drone Jammer frequencies the jamming radius up to 40meters.
Advantages
Full bands 22 Jammer Antenna chancel design, Customized for special frequency range
High output power, Total up to: 45W , jamming up to 40m (Still depends on the strength signal in given area)
External Omni-directional antennas all the TX frequency covered down link only
With Car storage battery Charger DC12V can be used in car
Built-in good cooling system inside, Working non-stopped
Can adjust or turn off any single band without influencing the other bands operation
2-5meters with Infrared Remote Control Turn ON /OFF Power
OEM Customized Service
Silkscreen OEM service can be offered
Application
It can be applied at meeting rooms, conference rooms, museums, galleries, theatres, concert halls, churches, temples, restaurants, classrooms, training centers, factories, banks, trains, bus and more Places that require silence, confidentiality and information security
For some locations of special purpose such as hospitals, gas stations and more, please do field test first to make sure no interference happened to the normal operation of their equipment and instrument
|
Key technical specifications: A22 EU |
|||
|
Channel |
Output port |
Frequency range |
Average out-putting power |
|
1 |
CDMA/RC868 |
850-894MHz |
35dbm / 3W |
|
2 |
GSM |
925-960MHZ |
35dbm / 3W |
|
3 |
DCS |
1805-1880MHZ |
33dbm / 2W |
|
4 |
3G |
2110-2170MHZ |
33dbm / 2W |
|
5 |
4G800 |
758-821MHZ |
35dbm / 3W |
|
6 |
4G2600 |
2570-2690MHZ |
30dbm / 1W |
|
7 |
4G2500 |
2500-2570MHZ |
30dbm / 1W |
|
8 |
4G2300 |
2300-2400MHZ |
30dbm / 1W |
|
9 |
5G 1500 |
1427-1518MHZ |
33dbm / 2W |
|
10 |
5G 3.4G |
3300-3600MHZ |
30dbm / 1W |
|
11 |
5G 3.8G |
3600-3900MHZ |
30dbm / 1W |
|
12 |
5G 4.0G |
3900-4200MHZ |
30dbm / 1W |
|
13 |
WIFI 2.4G 11.b, g |
2400-2500MHZ |
30dbm / 1W |
|
14 |
WIFI 5.2G 11.a |
4900-5500MHZ |
30dbm / 1W |
|
15 |
WIFI 5.8G 11.a |
5500-5900MHZ |
30dbm / 1W |
|
16 |
GPS: L1 + Glonass L1 |
1570-1580Mhz |
33dbm / 2W |
|
17 |
GPSL2+L5 + Glonass L2 |
1170-1280MHZ |
33dbm / 2W |
|
18 |
GPSL3+L4 |
1370-1390MHZ |
33dbm / 2W |
|
19 |
Lojack Car Tracking |
167-175MHZ |
35dbm / 3W |
|
20 |
VHF |
135-175Mhz |
35dbm / 3W |
|
21 |
UHF/RC433 |
400-470MHZ |
35dbm / 3W |
|
22 |
RC315 |
315MHZ |
35dbm / 3W |
|
Power supply: AC adapter 50 to 60Hz,( 63666480,110 or 220V AC-12V DC) Car storage battery Charger DC12V |
|||
|
Dimensions: (length ,width, height) 450x 238x 60mm（not Include Antenna） |
|||
|
Packing size: 55*44*15cm Net weight: 7kg Gross weight: 8.0kg |
|||
|
Total power:42W Shielding radius: (2-40) meters At -75dBm Still depends on the strength signal in given area, Shielding radius of VHF/UHF signal about 10meters |
|||
|
Warranty: one year from delivery date |
|||
|
Key technical specifications: A22 US |
|||
|
Channel |
Output port |
Frequency range |
Average out-putting power |
|
1 |
CDMA/RC868 |
850-894MHz |
35dbm / 3W |
|
2 |
GSM/LORA |
900-960MHZ |
35dbm / 3W |
|
3 |
DCS/PCS |
1805-1990MHZ |
33dbm / 2W |
|
4 |
3G, UMTS |
2110-2180MHZ |
33dbm / 2W |
|
5 |
4G700 |
700-803MHZ |
35dbm / 3W |
|
6 |
4G2600 |
2496-2690MHZ |
30dbm / 1W |
|
7 |
4G1700 |
1710-1780MHZ |
33dbm / 2W |
|
8 |
4G2300 |
2345-2400MHZ |
30dbm / 1W |
|
9 |
5G 600 |
617-675MHZ |
35dbm / 3W |
|
10 |
5G 3.4G |
3300-3600MHZ |
30dbm / 1W |
|
11 |
5G 3.8G |
3600-3900MHZ |
30dbm / 1W |
|
12 |
5G 4.0G |
3900-4200MHZ |
30dbm / 1W |
|
13 |
WIFI 2.4G 11.b, g |
2400-2500MHZ |
30dbm / 1W |
|
14 |
WIFI 5.2G 11.a |
4900-5500MHZ |
30dbm / 1W |
|
15 |
WIFI 5.8G 11.a |
5500-5900MHZ |
30dbm / 1W |
|
16 |
GPS: L1 + Glonass L1 |
1570-1580Mhz |
33dbm / 2W |
|
17 |
GPSL2+L5 + Glonass L2 |
1170-1280MHZ |
33dbm / 2W |
|
18 |
GPSL3+L4 |
1370-1390MHZ |
33dbm / 2W |
|
19 |
Lojack Car Tracking |
167-175MHZ |
35dbm / 3W |
|
20 |
VHF |
135-175Mhz |
35dbm / 3W |
|
21 |
UHF/RC433 |
400-470MHZ |
35dbm / 3W |
|
22 |
RC315 |
315MHZ |
35dbm / 3W |
|
Power supply: AC adapter 50 to 60Hz,( 63666481,110 or 220V AC-12V DC) Car storage battery Charger DC12V |
|||
|
Dimensions: (length ,width, height) 450x 238x 60mm（not Include Antenna） |
|||
|
Packing size: 55*44*15cm Net weight: 7kg Gross weight: 8.0kg |
|||
|
Total power:45W Shielding radius: (2-40) meters At -75dBm Still depends on the strength signal in given area, Shielding radius of VHF/UHF signal about 10meters |
|||
|
Warranty: one year from delivery date |
|||
