60-degree 2835 SMD LED Lens Series Blue Color

60-degree 2835 SMD LED Lens Series Blue Color

$0.01

≥10000 Piece/Pieces

Min. Order:: 10000 Piece/Pieces

Min. Order:: 10000 Piece/Pieces

Transportation:: Ocean, Land, Air, Express

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	100000000000
Supply Ability:	100000000000
Payment Type:	T/T,Paypal
Incoterm:	FOB,CIF,EXW,FCA,Express Delivery
Certificate:	ISO:9001
HS Code:	854140090
Transportation:	Ocean,Land,Air,Express

Product Description

2835BCA60 is a 2835 SMD LED that with dome lens on the top, which can replace some DIP LED during the application. In order to fit with more project on the application, we can offer some dome lens SMD LED that with much more economy price in ths blue SMD LED.

The dome lens 2835 SMD LED is a high perfomance SMD LED designed for a wide range of lighting applications. In this page, we show the dome lens 2835 SMD LED with a 60 degree viewing angle and blue color in 455-465nm wavelength range is versatile and efficient lighting solution. Its combination of high brightness, wide viewing angle and compact design makes it suitable for different kinds of application, such as deorative lighting, industrial uses. Whether you're designing a new product or upgrading and existing one. This LED offers the performance and reliability you need~

Size of Blue SMD LED:

*Soldering confition: Soldering confition must be completed with 3 secongds at 260℃

Parameter	Symbol	Rating	Unit
Forward Current	IF	20	mA
Forward Voltage	V	2.8-3.4	v
Luminous Intensity	IV	300-600	mcd
Wavelength	λP	465nm	nm
Packing	Piece	2000	Reel
Viewing angle	2θ1/2	60	Deg
