5mm Red LED Without Edges 620nm Clear Lens

All the SMD LED and LED Lamp (Through-hole LED) are electronics components. 5mm light emitting diode are also one of the electronics components that widely use in kinds of lighting project or PCB board. The only different between 513ERC62D3L12 and 503ERC62D3L12 is the edges(or the collar) at the bottom of LED lamps lens. This is a super bright red through-hole LED with transparent lens as follow. Similar with most of 5mm red LED, it also got the 5mm diameter. In this 513ERC62D3L12, there are the totally cylindrical epoxy lens from the top to bottom. Which have no any edges on the epoxy lens, that will make LED fit into the PCB or case totally without any block.

SMD LED Features:

Dimension: 5mm;

Wavelength: 980nm LED;

Lens type: Clear epoxy;

High reliability and high radiation intersity;

Electrical Parameters:

*Pulse forward current confition: Duty 1% and Pulse width=10us.

*Soldering confition: Soldering confition must be completed with 3 secongds at 260℃

*Luminous intensity is measured by ZWL600.

*λD is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.
